Scattering-Filling Stone Concrete: Mechanism, Experiment and Utilization

Abstract:

The coarse aggregate volume fraction in conventional plastic concrete is controlled relatively low to ensure a required workability, but its low aggregate content play negative roll on the service properties of the concrete. In this paper, we revealed the mechanism of a coarse aggregate interlocking concrete prepared by Scattering-Filling Stone Concrete (SFSC), it can keep the fresh concrete its workability but increase its service performance by scattering coarse aggregate during the concrete casting, the experimental and engineering application of SFSC indicated that: the strength of concrete prepared with this method increases obviously whereas the shrinkage decreases significantly when 20% cement dosage is saved. The SFS process was utilized in a highway pavement, the core of the concrete is very dense and no obvious defect could be found when 8% pavement concrete was replaced by coarse aggregate. The SFSC is a type of low carbon concrete.

• Periodical: Key Engineering Materials (Volumes 629-630)
• Pages: 522-527
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.629-630.522
• Online since: October 2014
• Authors: Wei Guo Shen*, Zhen Guo Yang, Zhi Feng Yang, Jiang Feng Li, Liu Cao, Chuan Zhang
• Keywords: Aggregate Interlocking Concrete, Coarse Aggregate, Interfacial Transition Zone, Scattering-Filling Stone Process, Shrinkage, Strength

References

[1] Mehta P K. Concrete technology for sustainable development. Concrete Intern 1999; 21(11): 47-53.

[2] Mizuguchi H. A review of environmentally friendly concrete. Concrete Intern. 1998; 36(1): 9-12.

[3] Van Oss H G, Padovani A C. Cement Manufacture and the Environment, Part II: Environmental Challenges and Opportunities. J Industr Ecol. 2003; 7, (1): 93-126.

DOI: 10.1162/108819803766729212

[4] A.U. Nilsen, P.J. M Monteiro. Concrete: A Three Phase Material. Cement and Concrete Res. 1993. 23(2): 147-151.

DOI: 10.1016/0008-8846(93)90145-y

[5] Özturan T, Çeçen C. Effect of coarse aggregate type on mechanical properties of concretes with different strengths. Cement Concrete Res. 1997; 27(2): 165-170.

DOI: 10.1016/s0008-8846(97)00006-9

[6] Beshr H, Almusallam A. A, Maslehuddin M. Effect of coarse aggregate quality on the mechanical properties of high strength concrete. Constr Build Mater 2003; 17(2): 97-103.

DOI: 10.1016/s0950-0618(02)00097-1

[7] Stock A F, Hannant D J, Williams R I T. The effect of aggregate concentration upon the strength and modulus of elasticity of concrete. Mag Concrete Res 1979; 31(2): 225– 234.

DOI: 10.1680/macr.1979.31.109.225

[8] Counto U.J. The effect of elastic modulus of the aggregate on the elastic modulus, creep and creep recovery of concrete, Mag Concrete Res. 1964; 16(2): 129.

DOI: 10.1680/macr.1964.16.48.129

[9] Hirsch, T.J. Modulus of elasticity of concrete affected by elastic module of cement paste matrix and aggregate, ACI Mater J 1962; 59(3): 427–451.

DOI: 10.14359/7924

[10] Alexanderson J. The influence of the properties of Cement and aggregates on the consistency of concrete. Proc. RILEM Seminar 1971; 23(2): 12-22.

[11] Mehta P K, Monteiro P J M. Concrete: Microstructure, Properties, and Materials, New York, McGraw-Hill, (1993).

[12] Shen W, Zhang T , Zhou M, et al. Investigation on the scattering-filling stone self-consolidating concrete. Materials and structures, 2010, 43 (10): 1343–1350.

DOI: 10.1617/s11527-010-9585-9

[13] Shen W, Dong R, Li J et al. A study on the coarse aggregate interlocking concrete, Construction and building material, 2010, 24(11) 2312–2316.

DOI: 10.1016/j.conbuildmat.2010.04.023

[14] Shen W, Cai Z, Zhou M. High Strength Coarse Aggregate Interlocking Concrete: Preparation And Properties, 8th International sympsum on utilization of High-strength and High performance concrete (fib), 2008, Tokyo, 188-192.

[15] Beste U, Jacobson S, Micro scale hardness distribution of rock types related to rock drill wear, Wear 2003, 254 (5): 1147–1154.

DOI: 10.1016/s0043-1648(03)00327-2

[16] Neville F.M. Properties of concrete. London, Pitman publishing limited, (1981).

[17] Mindess S, Young J F, David D. Concrete (Second Edition), New Jersey. Pearson Education, Inc. (2003).
