Riser Design of Cast System of Fused Zirconia-Alumina-Silica

Abstract:

Fused cast Zirconia-Alumina-Silica material (AZS) is the key refractory to glass furnace. In order to reduce production cost and optimize production process, the influences of riser position and riser size on temperature gradient, solidification time, residual melt modulus, solidification fraction, and cooling rate of cast system were studied by the finite element simulation method according to the brick size of 600 mm × 400 mm × 300 mm. It turned out that it would be more efficient in feeding when riser located at the center of maximum surface of a brick or when the height of riser is 250 mm-270 mm, while the volume ratio of brick to riser is 2.95-2.74, on condition that the size of riser upper surface is 450 mm × 450 mm and the bottom 150 mm×150 mm.

You might also be interested in these eBooks

Testing and Evaluation of Inorganic Materials V

View Preview

Info:

Periodical:

Key Engineering Materials (Volume 633)

Pages:

498-502

DOI:

https://doi.org/10.4028/www.scientific.net/KEM.633.498

Citation:

Cite this paper

Online since:

November 2014

Authors:

Dao Yuan Yang*, Min Xiao Ma, Ruo Yang Liu, Yue Chu, Yi Ming Yin, Luo Yuan Li, Guan Hui Wan

Keywords:

Fused Cast AZS Material, Riser Height, Riser Position, Solidification Time, Temperature Gradient

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

* - Corresponding Author

References

[1] F. Yuan, D.Y. Yang, T. Wang. Effects of graphite mold on cooling process of fused AZS 33# refractory, J. Key engineering materials, 544 (2013) 110-114.

DOI: 10.4028/www.scientific.net/kem.544.110

Google Scholar

[2] W Xia, Z.G. Wang, C.M. Liu. Computer simulation of cooling process of the fused case AZS33 refractories using finite element model. Metallurgical Industry Automation. 35 (2011) 29-35.

Google Scholar

[3] Information on http: /www. paper. edu. cn/releasepaper/content/201111-104.

Google Scholar

[4] Y.S. Guo. Influence of cooling rate on the mechanical properties and porosity content of high strength aluminum alloy castings, J. Foundry Technology. 11 (2008) 1513-1517.

Google Scholar
