Mechanical Behavior of Self-Compacting Soil-Cement-Sisal Fiber Composites

Abstract:

The aim of this research is the development and mechanical characterization of self-compacting soil cement composites with the incorporation of fly ash, metakaolin and sisal fibers. The mentioned composites, based on natural raw materials (raw earth and vegetable fibers), which are abundant in nature and have low cost and low environmental impact could be used as a more sustainable alternative than conventional industrialized materials for applications that don ́t require high structural performance (minimum strength equals to 2 MPa). A residual soil, constituted by 35% of fines and 65% of granular material was selected and the matrix was designed using a computational routine, based on the compressible packing model (CPM). The rheology of the matrix was adjusted by the slump flow test having as a target the spreading value of 600 mm. The matrix presented uniaxial compression strength of about 3.3 MPa after 28 days of curing. After 240 days of curing it was noticed an increase in the compressive strength to 7.5 MPa. This can be traced back to the pozzolanic reactions that takes place in the system. The soil cement composites were produced with three different sisal fiber contents: 0.5, 1.0 and 1.5% (in relation to the weight of dry soil) and a fiber length (L_e) of 20 mm. Under compression, the incorporation of fibers has significantly influenced the post-peak behavior, increasing the toughness and the strain capacity. Under four point bending loading, the presence of fibers have contributed to increase the peak strength and the residual strength with expressive gains of toughness. The composites presented strength values as high as 1.8 MPa (1.0% of fibers) when they were subjected to bending loads. The use of sisal fibers as reinforcement modified the fracture mechanisms of the composites, changing it from a brittle to a ductile behavior.

• Periodical: Key Engineering Materials (Volume 634)
• Pages: 421-432
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.634.421
• Online since: December 2014
• Authors: A.P.S. Martins*, F.A. Silva, Romildo Dias Toledo Filho
• Keywords: Compressible Packing Model, Mechanical Behavior, Self-Compacting Matrix, Sisal Fibers, Soil Cement Composites

References

[1] Houben, H. e Guillaud, H., 1994, Earth Construction. 1ª ed . UK, Pratical Action Publishing.

[2] Heathcote, K.A., 1995, Durability of earthwall buildings, Construction and Building Materials, v. 9, n. 3, pp.185-189.

DOI: 10.1016/0950-0618(95)00035-e

[3] Walker, P. J., 1995, Strength, Durability and Shrinkage Characteristics of Cement Stabilised Soil Blocks, Cement and Concrete Composites, v. 17, pp.301-310.

DOI: 10.1016/0958-9465(95)00019-9

[4] Walker, P., 2004, Strength and Erosion Characteristics of Earth Blocks and Earth Block Masonry, Journal of Materials in Civil Engineering, v. 16, n. 5 (october), pp.497-506.

DOI: 10.1061/(asce)0899-1561(2004)16:5(497)

[5] Bouhicha, M., Aouissi, F., Kenai, S., 2005, Performance of composite soil reinforced with barley straw, Cement & Concrete Composites, v. 27, n. 5, pp.617-621.

DOI: 10.1016/j.cemconcomp.2004.09.013

[6] Guettala, A., Abibsi, A., Houari, H., 2006, Durability study of stabilized earth concrete under both laboratory and climatic conditions exposure, Construction and Building Materials, v. 20, pp.119-127.

DOI: 10.1016/j.conbuildmat.2005.02.001

[7] Bui, Q. B., Morel, J. C., Venkatarama Reddy, B. V., Ghayad, W., 2009, Durabilitity of rammed walls exposed for 20 years to natural weathering, Building and Environment, v. 44, pp.912-919.

DOI: 10.1016/j.buildenv.2008.07.001

[8] Silva, R.A., Oliveira, D.V., Miranda, T., Cristelo, N., Escobar, M.C., Soares, E., 2013, Rammed Earth construction with granitic residual soils: The case study of northern Portugal, Construction and Building Materials, v. 47, pp.181-191.

DOI: 10.1016/j.conbuildmat.2013.05.047

[9] Consoli, N.C., Zortéa, N. F., Souza, M., Festugato, L., 2011, Studies on the Dosage of Fiber-Reinforced Cemented Soils,. Journal of Materials in Civil Engineering, v. 23 (dec) n. 12 pp.1624-1632.

DOI: 10.1061/(asce)mt.1943-5533.0000343

[10] Da Rocha, C.G., Consoli, N.C., Johann, A.D. R, 2013, Greening stabilized rammed earth: devising more sustainable dosages based on strength controlling equations, Journal of Cleaner Production, http: /dx. doi. org/10. 1016/j. jclepro. 2013. 11. 041, (in press).

DOI: 10.1016/j.jclepro.2013.11.041

[11] Cristelo, N., Glendinning, S., Miranda, T., Oliveira, D., Silva, R., 2012, Soil Stabilization using alcaline activation of fly ash for self compacting rammed earth construction, Construction and Building Materials, v. 36 (nov), pp.727-735.

DOI: 10.1016/j.conbuildmat.2012.06.037

[12] Ghavami, K., Toledo Filho, R.D., Barbosa, N.P., 1999, Behavior of composite reinforced with natural fibres, Cement & Concrete Composites, v. 21, n. 1, pp.39-48.

DOI: 10.1016/s0958-9465(98)00033-x

[13] Mesbah, A., Morel, J.C., Walker, P., Ghavami, Kh., 2004, Development of a Direct Tensile Test for Compacted Earth Blocks Reinforced with Natural Fibers, Journal of Materials in Civil Engineering, v. 16, n. 1 (February), pp.95-98.

DOI: 10.1061/(asce)0899-1561(2004)16:1(95)

[14] Binici, H., Aksogan, O., Shah, T., 2005, Investigation of fibre reinforced mud brick as a building material, Construction and Building Materials, v. 19, pp.313-318.

DOI: 10.1016/j.conbuildmat.2004.07.013

[15] Mattone, R., 2005, Sisal fibre reinforced soil with cement or cactus pulp in bahareque technique, Cement and Concrete Composites. v. 27, n. 5 (may), pp.611-616.

DOI: 10.1016/j.cemconcomp.2004.09.016

[16] Segetin, M., Jayaraman, K., Xu X., 2007, Harakeke reinforcement of soil-cement building materials: manufacturability and properties, Building and Environment, v. 42, n. 8, pp.3066-3079.

DOI: 10.1016/j.buildenv.2006.07.033

[17] Quagliarini, E., Lenci, S., 2010, The influence of natural stabilizers and natural fibres on the mechanical properties of ancient Roman adobe bricks, Journal of Cultural Heritage, v. 11, pp.309-314.

DOI: 10.1016/j.culher.2009.11.012

[18] Hejazi, S.M., Sheikhzadeh, M., Abtahi, S.M., Zadhoush, A., 2012, A simple review of soil reinforcement by using natural and synthetic fibers, Construction and Building Materials, v. 30 (may), pp.100-116.

DOI: 10.1016/j.conbuildmat.2011.11.045

[19] Binici, H., Aksogan, O., Bodur, M.N., Akca, E., Kapur, S., 2007, Thermal isolation and mechanical properties of fibre reinforced mud bricks as wall materials, Construction and Building Materials, v. 21, n. 4 (april), pp.901-906.

DOI: 10.1016/j.conbuildmat.2005.11.004

[20] Yetgin, S., Çavdar, Ö., Çavdar, A., 2008, The effects of the fiber contents on the mechanic properties of the adobes, Construction and Building Materials, v. 22, pp.222-227.

DOI: 10.1016/j.conbuildmat.2006.08.022

[21] Chan, C., 2011, Effect of Natural Fibers Inclusion in Clay Bricks: Physico-Mechanical Properties, International Journal of Civil Environmental Engineering, v. 3, n. 1, pp.51-57.

[22] Tang, C., Shi, B., Gao, W., Chen, F., Cai, Y., 2007, Strength and mechanical behavior of short polypropylene fiber reinforced and cement stabilized clayey soil, Geotextiles and Geomembranes, v. 25, n. 3, pp.194-202.

DOI: 10.1016/j.geotexmem.2006.11.002

[23] Aymerich, F., Fenu, L., Meloni, P., 2012, Effect of reinforcing wool fibres on fracture and energy absorption properties of an earthen material, Construction and Building Materials, v. 27, pp.66-72.

DOI: 10.1016/j.conbuildmat.2011.08.008

[24] De Larrard, F., 1999, Concrete Mixture Proportioning. London, E&FN SPON.

[25] Sedran, T., 1999, Rheology et rheometry of concretes. Application to self-compacting concretes. Doctoral thesis, National School of Bridges and Highways, Paris, France, 220p. (in french).

[26] Brazilian Standard Association, 1995, Rocks and Soils: NBR 6502. Rio de Janeiro, Brazil. (in portuguese).

[27] ASTM – American Society for Testing and Materials, 2008, Standard Practice for Classification of Soils for Engineering Purposes": D2487-11. West Conshohocken, PA, USA.

[28] Brazilian Standard Association, 1984, Soil – Determination of the Liquid Limit: NBR 6459. Rio de Janeiro, Brazil. (in portuguese).

[29] Brazilian Standard Association, 1984, Soil – Determination of the Plasticity Limit: NBR 7180 Corrected Version 1988. Rio de Janeiro, Brazil. (in portuguese).

[30] ASTM – American Society for Testing and Materials, 1998, Standard Specification for Coal Fly Ash and Raw or Calcined Natural Pozzolan for Use as a Mineral Admixture in concrete: C618. Philadelphia, USA.

DOI: 10.1520/c0618-00

[31] Toledo Filho, R.D., 1997, Composite Materials Reinforced with Natural Fibers: Experimental Characterization. Ph.D. Thesis, DEC-PUC-RIO / DEC-Imperial College-Londres, Rio de Janeiro, RJ, Brasil. (in portuguese).

[32] Silva, F.A., Chawla, N., Toledo Filho, R.D., 2008, Tensile behavior of high performance natural (sisal) fibers, Composites Science and Technology, v. 68, pp.3438-3443.

DOI: 10.1016/j.compscitech.2008.10.001

[33] Silva, A.S.M., 2004, Concrete Dosage by Compressible Packing Model Method and Modified Aïtcin-Faury Method. Master´s Thesis, COPPE/UFRJ, Rio de Janeiro, RJ, Brazil. (in portuguese).

[34] Cordeiro, G.C., 2006, Utilization of Ultrafine Ashes from Sugar Cane Bagasse and Rice Husk as Mineral Additives in Concrete. Doctoral Thesis, COPPE/UFRJ, Rio de Janeiro, RJ, Brazil. (in portuguese).

[35] Brazilian Standard Association, 1998, Concrete – Determination of the consistence by the Slump Test: NBR NM 67. Rio de Janeiro, Brazil. (in portuguese).

[36] Brazilian Standard Association, 2010, Self-compacting Concrete. Part 2: Determination of the slump flow and the flow time – Abrams Cone Method: NBR 15823-2. Rio de Janeiro, Brazil. (in portuguese).

[37] Brazilian Standard Association, 2007, Concrete – Test Method for Compressive Strength of Cylindrical Specimens: NBR 5739. Rio de Janeiro, Brazil. (in portuguese).
