Finite Element Analysis on Plastic Deformation Behaviors of Ti-3Al-2.5V Tubes under Axial Compression

Abstract:

With the requirement of aviation and aerospace fields for high-strength Ti-3Al-2.5V titanium alloy bent tubes with high-performance, it is great significance to research the plastic deformation of Ti-3Al-2.5V tubes under compression to obtain desired flow stress curves. A finite element (FE) model of axial compression of Ti-3Al-2.5V tubes was established in this study. Using this model, deformation behaviors of Φ12 mm × t0.9 mm Ti-3Al-2.5V tubes with different ratios of thickness to height (t/h) compressed under different frictions were analyzed. It is shown that the non-uniform deformation degree of the tubes increases with the decrease of t/h and the increase of friction coefficient. This means that a large t/h value and small friction can help to attain a uniaxial compression condition to obtain desired flow stress curves. Such compression conditions for the Φ12 mm × t0.9 mm Ti-3Al-2.5V tube is that, t/h is not less than 0.6 and the friction coefficient is not greater than 0.05

• Periodical: Key Engineering Materials (Volume 639)
• Pages: 551-558
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.639.551
• Online since: March 2015
• Authors: Tao Huang, Mei Zhan*, Jin Qiang Tan, Jing Guo, He Yang
• Keywords: Finite Element Method (FEM), Titanium

References

[1] H. Yang, X.G. Fan, Z.C. Sun, L.G. Guo, M. Zhan, Recent developments in plastic forming technology of titanium alloys, Sci. China. 54 (2011) 490-501.

DOI: 10.1007/s11431-010-4206-y

[2] M. Zhan, T. Huang, P.P. Zhang, H. Yang, Variation of young's modulus of high-strength TA18 tubes and its effects on forming quality of tubes by numerical control bending, Mater. Design. 53 (2014) 809-815.

DOI: 10.1016/j.matdes.2013.07.070

[3] M. Zhan, T. Huang, H. Yang. Variation of contractile strain ratio of Ti-3Al-2. 5V tubes and its effects in tubes numerical control bending process, J. Mater. Process. Technol. 217 (2015) 165-183.

DOI: 10.1016/j.jmatprotec.2014.11.019

[4] E. Azhikannickal, M. Jain, M. Bruhis, Test methods for the determination of the stress-strain behaviour of oriented polypropylene (OPP) tubes in axial compression, Polym. Test. 26 (2007) 195-201.

DOI: 10.1016/j.polymertesting.2006.10.001

[5] V.A.M. Cristino, P.A.R. Rosa, P.A.F. Martins, Surface roughness and material strength of tribo-pairs in ring compression tests, Tribol. Int. 44 (2011) 134-143.

DOI: 10.1016/j.triboint.2010.10.002

[6] J. Liu, Precision Prediction for the Effect of Stress State on Tube NC Rotary-draw Bending(Dissertation), Northwestern Polytechnical University, Xi'an, 2013 (in Chinese).

[7] T. Robinson, H. Ou, C.G. Armstrong, Study on ring compression test using physical modeling and FE simulation, J. Mater. Process. Technol. 153-154 (2004) 54-59.

DOI: 10.1016/j.jmatprotec.2004.04.045

[8] ASTM E8/E8M-11: Standard test methods for tension testing of metallic materials (2011).

[9] Y. Wang, H. Yang, H. Li, M. Zhan, F.F. Song, G.J. Li, X.D. Xu, Effect of springback on wall thinning and section distortion for high strength TA18 tube in NC bending, Rare. Metal. Mat. Eng. 41(2012) 1221-1225(in Chinese).

[10] R. Ebrahimi, A. Najafizadeh. A new method for evaluation of friction in bulk metal forming, J. Mater. Process. Technol. 152(2004) 136-143.

DOI: 10.1016/j.jmatprotec.2004.03.029
