Economical Comparison of Cryogenic vs. Traditional Turning of Ti-6Al-4V: A Case Study

Abstract:

Due to their poor machinability, titanium alloys need to be worked at low cutting speeds to prevent a fast tool failure caused by the very high temperatures that are reached at the tool-chip interface. As demonstrated by previous works by the authors, an improvement of productivity for Titanium alloys can be obtained by adopting cryogenic cooling during the machining operations.The present work shows the features of a toolholder specifically designed for cryogenic adduction in turning operations, following Hong’s design guidelines. The paper compares tool life results between traditional and cryogenic rough turning by adopting Grade 5 titanium as the working material. Rough turning is economically more relevant to the machining industry, especially in the aerospace field where generally a large quantity of rough material has to be removed due to the very high buy-to-fly ratio of aerospace components. A full factorial experimental plan was performed basing on typical rough turning parameters. Machining outputs such as forces, roughness, temperatures, friction coefficients were calculated in order to define statistical differences between cryogenic cooling method using the special toolholder and traditional oil water emulsion cooling system.Furthermore, thanks to tool life results the Taylor’s law for cryogenic and traditional cases was calculated and an hypothetical production scenario for Ti6Al4V parts was analysed. An analytical model to calculate production costs and time was built for both cooling methods. A 4-turrets turning centre was considered and cooling methods and costs per hour of machine tool were taken into account in a cost model. The results show that the benefits in terms of tool life offered by liquid nitrogen cooling allows to improve productivity by adopting higher optimal cutting parameters. This improvement, coupled to an increase of tool life, is very significant and allows not only to reduce time of production but also to cover the major costs of liquid nitrogen and have a slight reduction of machining total costs.

• Periodical: Key Engineering Materials (Volumes 651-653)
• Pages: 1204-1210
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.651-653.1204
• Online since: July 2015
• Authors: Stefano Tirelli, Elio Chiappini, Matteo Strano*, Michele Monno, Quirico Semeraro
• Keywords: Cryogenic Cooling, Economic, Emulsion Cooling, Insert, Optimization, Productivity, Ti6Al4V, Titanium Alloys, Tool Wear, Turning

References

[1] Z.M. Ezugwu, E.O., Zwang - Titanium alloys and their machinability, a review, J. Mat. Proc. Tech. 68 (1995) 262-274.

[2] S. Tirelli, E. Chiappini, M. Strano, M. Monno, Q. Semeraro, Experimental Comparison between Traditional and Cryogenic Cooling Conditions in Rough Turning of Ti-6Al-4V, Key Eng. Mater. (2014) 1174–1185.

DOI: 10.4028/www.scientific.net/kem.611-612.1174

[3] S.Y. Hong, Y. Ding, Cooling approaches and cutting temperatures in cryogenic machining of Ti-6Al-4V, Int. J. Mach. Tools Manuf. 41 (2001) 1417–1437.

DOI: 10.1016/s0890-6955(01)00026-8

[4] S. Hong, I. Markus, W. Jeong, New cooling approach and tool life improvement in cryogenic machining of titanium alloy Ti-6Al-4V, Int. J. Mach. Tools Manuf. 41 (2001) 2245–2260.

DOI: 10.1016/s0890-6955(01)00041-4

[5] F. Pusavec, J. Kopac, Achieving and implementation of sustainability principles in machining processes, Adv. Prod. Eng. Manag. 4 (2009) 151–160.

[6] S. Hong, M. Broomer, Economical and ecological cryogenic machining of AISI 304 austenitic stainless steel, Clean Prod. Process. 2 (2000) 0157–0166.

DOI: 10.1007/s100980000073

[7] M.J. Bermingham, S. Palanisamy, M.S. Dargusch, Understanding the tool wear mechanism during thermally assisted machining Ti-6Al-4V, Int. J. Mach. Tools Manuf. 62 (2012) 76–87.

DOI: 10.1016/j.ijmachtools.2012.07.001

[8] M. Santochi, F. Giusti, Tecnologia meccanica e studi di fabbricazione, (2000).

[9] S. Nakashima, Z. Wang, M. Larson, Cost Effective Machining of Ti-6Al-4V Using State-of-the- Art Machining Centers, in: 42nd NAMRC. SME, Detroit, (2014).
