Inverse Thermal Analysis of Melting Pool in Selective Laser Melting Process

Abstract:

The Selective Laser Melting (SLM) process of metallic powder is an additive technology. It allows the production of complex-shaped parts which are difficult to obtain by conventional methods. The principle is similar to Selective Laser Sintering (SLS) process: it consists, from an initial CAD model, to create the desired part layer by layer. The laser scans a powder bed of 40 μm thick. The irradiated powder is instantly melted and becomes a solid material when the laser moves away. A new layer of powder is left and the laser starts a new cycle of scanning. The sudden and intense phase changing involves high thermal gradients which induce contraction and expansion cycles in the part. These cycles results in irreversible plastic strains. The presence of residual stresses in the manufactured part can damage the mechanical properties, such as the fatigue life. This study focuses on the thermal and mechanical modelling of the SLM process. One of the key points of the mechanical modelling is the determination of the heat source generated by the laser in order to predict residual stresses. This work is divided in three parts. In a first part, an experimental protocol is established in order to measure the temperature variation during the process. In the second part, a thermal model of the process is proposed. Finally, an inverse method to determine the power and the shape of the heat source is developed. Experimental and computational results are fitted. The influence of several geometries of the heat source is investigated.

• Periodical: Key Engineering Materials (Volumes 651-653)
• Pages: 1519-1524
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.651-653.1519
• Online since: July 2015
• Authors: Laurent van Belle*, Alban Agazzi
• Keywords: FEM, Inverse Method, Selective Laser Melting, Thermal Analysis

References

[1] A. Agazzi, V. Sobotka, R. Le Goff and al, Optimal cooling design in injection moulding process: A new approach based on morphological surfaces, Applied Thermal Engineering Vol 52 (2013) 170-178.

DOI: 10.1016/j.applthermaleng.2012.11.019

[2] P. Mercelis and J.P. Kruth, Residual stresses in selective laser sintering and selective laser melting, Rapide Prototyping Journal Vol. 12, issue 5 (2006) 254-265.

DOI: 10.1108/13552540610707013

[3] L. Van Belle, analyse, modélisation et simulation de l'apparition de contraintes en fusion laser métallique, Villeurbanne, (2013).

[4] Y. Zhang, G. Yu, X. He and al, Numerical and experimental investigation of multilayer SS410 thin wall built by laser direct metal deposition, Journal of Materials Prcessing Technology 212 (2012) 106-112.

DOI: 10.1016/j.jmatprotec.2011.08.011

[5] R.B. Patil and V. Yadava, Finite element analysis of temperature distribution in single metallic powder layer during metal laser sintering, International Journal of Machine Tools & Manufacture 47 (2007) 1069-1080.

DOI: 10.1016/j.ijmachtools.2006.09.025

[6] K. Dai and L. Shaw, Finite element analysis of the effect of volume shrinkage during laser densification, Acta Materialia (2005) 4743-4754.

DOI: 10.1016/j.actamat.2005.06.014

[7] A. Plati, J.C. Tan, I.O. Golosnoy and al, Residual stress Generation during Laser Cladding of Steel with a Particulate Metal Matrix Composite, Advanced Engineering Materials Vol 8, Issue 7 (2006) 619-624.

DOI: 10.1002/adem.200600063

[8] J. Ding, P. Colegrove, J. Mehnen and al, Thermo-mechanical analysis of Wire and Arc Additive Layer Manufacturing process on large multi-layers parts, Computational Materials Science Vol 50, Issue 12 (2011) 3315-3322.

DOI: 10.1016/j.commatsci.2011.06.023
