Heat Transfer and Crystallization Modeling during Compression Molding of Thermoplastic Composite Parts

Abstract:

We present in this paper, the coupling of heat transfer to the crystallization of composite in a closed mold. The composite is based on thermoplastic resin (low viscosity PA 66) with glass fiber (50% volume fraction). In order to realize this coupling, an accurate characterizationof thermo physical properties in process conditions, especially in the molten and solid state is needed. In addition, theidentification of the parameters of crystallization kinetics is required. Therefore, we present the methods that were used to study the thermo physical properties as the thermal conductivity, heat capacity and the specific volume. Moreover, the kinetic of crystallization was estimated over a large temperature range by using Flash DSC and classical DSC. In order to validate the measurements, the whole process was modeled by finite elements. The model includes the resolution of the strong coupling between the heat transfer and crystallization. Finally, the experimental and numerical results were compared.

• Periodical: Key Engineering Materials (Volumes 651-653)
• Pages: 1507-1512
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.651-653.1507
• Online since: July 2015
• Authors: Jalal Faraj*, Baptiste Pignon, Jean Luc Bailleul, Nicolas Boyard, Didier Delaunay, Gilles Orange
• Keywords: Crystallization, Heat Transfer, PA 66, Thermophysical Properties, Thermoplastic Composite
