Energetic Consideration of the Spark Erosion Using Different Process Energy Sources and Pulse-Unit-Gap Conditions

Abstract:

The energetic calculations of pulse energies are only very rough approximations in many publications, because some boundary conditions are not known or are not considered. In the paper is shown that problems resulting from the choice of process energy source and the supply-gap conditions. Approximations that were still considered for long pulse durations, for example, can for micro and nanoEDM no longer be accepted. The smaller the pulse energy, it can also not allow for the simulation of a linear rising enthalpy may be used. The shifts between the measured current and voltage must not be neglected. Practical tests to have shown, that the peak of the energy input is shifted in time and the maximum is lower by about 70%. The parasitic capacitances of the connection pulse unit - working gap and electrode arrangement results in the largest errors in the power calculation. It follows that the connection conditions of industrial plants may not be changed or should be recalculated.

• Periodical: Key Engineering Materials (Volumes 651-653)
• Pages: 701-706
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.651-653.701
• Online since: July 2015
• Authors: Hans Peter Schulze*
• Keywords: Electrical Discharge Machining, Process Energy Source, Pulse Energy

References

[1] G. Wollenberg, H. -P. Schulze, M. Timm, Th. Pape, Simulation of EDM Installations. Proceedings of the International Symposium for ElectroMachining, April 17-21, 1995 EPFL Lauseanne, Switzerland, pp.153-162.

[2] M. Läuter, H. -P. Schulze, G. Wollenberg, Modern process energy sources for electrical discharge machining (EDM). 18 th International Conference Computer-aided Production Engineering (CAPE), Professional Engineering Publ. 2003, pp.339-348.

[3] G. Wollenberg, H. -P. Schulze, Th. Pape, M. Läuter, Moderne Generatortechnik für die funkenerosive Bearbeitung. 4. Aachener Fachtagung Funkenerosive Bearbeitung, 1999, 4. bis 5. 11. 1999, pp.1-29.

DOI: 10.1007/978-3-663-02467-5_2

[4] M. D. Nguyen, M. Rahman, Y.S. Wong, An experimental study on Micro-EDM in low-resistivity deionized water using short voltage pulses. Int. J. Adv. Manuf. Technology (2012) 58: 533-544.

DOI: 10.1007/s00170-011-3397-0

[5] M. Zahiruddin, M. Kunieda, Comparison of energy and removal efficiencies between micro and macro EDM. CIRP Annals – Manufacturing Technology 61 (2012), 187-190.

DOI: 10.1016/j.cirp.2012.03.006

[6] H. -P. Schulze, L. Slatineanu, M. Coteata, Factoring on the Tool Wear at Various Dimensional Structures during the Electro-Discharge Machining. 14th Intern. Conference on Material Forming. – Melville, NY. American. Inst. of Physics, AIP Kongress ESAFORM 14 (Belfast, UK) 1344-1349.

DOI: 10.1063/1.3589698

[7] B. Izquierdo, S. Plaza, J.A. Sanchez, I. Pombo, N. Ortega, Numerical prediction of heat affected layer in the EDM of aeronautical alloys. Applied Surface Science 259 (2012) 780-790.

DOI: 10.1016/j.apsusc.2012.07.124
