Computer Simulation of the Half-Tore Forming Process from a Ring Blank

Abstract:

This paper presents the theoretical foundations and methodology of the modeling process of forming a half ring alloy blank AMg5M in software product Pam-Stamp. At the following technological sizes of a half-tore: the blank radius 516.5 mm; hole’s radius R₀=480.74 mm, distance from the generating circle center to the axis of rotation R₁=714 mm, the generating circle radius R_p=93 mm, curvature radius of die R_d=16 mm, the process is stable. The results of numerical analysis of the drawing half-tore from the ring blank directed to determining the optimal process parameters are revealed. Modeling shows that the size of the holes in the blank has a significant influence on the distribution of strain along the generatrix of the stamped parts. Using the ring blank reduces the probability of wrinkling in the free areas.

• Periodical: Key Engineering Materials (Volume 684)
• Pages: 227-233
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.684.227
• Online since: February 2016
• Authors: Ilmira Suleymanova, Aleksey Shlyapugin, Yaroslav A. Erisov*
• Keywords: Aluminum Alloy AA5056, Drawing, Half-Tore, Pam-Stamp, Ring Blank, Simulation, Wrinkling

References

[1] Afanasiev I.B., Baturin Y.M., Belozersky A.G. et al. World Manned Space Program. History. Appliances. People [M]. Moscow: RTSoft, 2005. (in Russian).

[2] Bruschi S.S., Altan T., Banabic D., Bariani P.F., Brosius A., Cao J., Ghiotti A., Khraisheh M., Merklein M., Tekkaya A.E. Testing and Modeling of Material Behavior and Formability in Sheet Metal Forming [J]. CIRP Annals - Manufacturing Technology, 2014, 63(2): 727-749.

DOI: 10.1016/j.cirp.2014.05.005

[3] Kim Y., Son Y. Study on Wrinkling Limit Diagram of Anisotropic Sheet Metals [J]. Journal of Materials Processing Technology, 2000, 97(1-3): 88-94.

DOI: 10.1016/s0924-0136(99)00346-5

[4] Yagami T., Manabe K., Yamauchi Y. Effect of Alternating Blank Holder Motion of Drawing and Wrinkle Elimination on Deep-Drawability [J]. Journal of Materials Processing Technology, 2007, 6: 187-191.

DOI: 10.1016/j.jmatprotec.2006.11.180

[5] Demirci H.I., Yasar M., Demirayb K., Karal M. The Theoretical and Experimental Investigation of Blank Holder Forces Plate Effect in Deep Drawing Process of AL 1050 Material [J]. Materials & Design, 2008, 29(2): 526-532.

DOI: 10.1016/j.matdes.2007.01.008

[6] Ahmetoglu M., Broek T.R., Kinzel G., Altan T. Control of Blank Holder Force to Eliminate Wrinkling and Fracture in Deep-Drawing Rectangular Parts [J]. Manufacturing Technology, 1995, 44(1): 247–250.

DOI: 10.1016/s0007-8506(07)62318-x

[7] Romanovsky V.P. Handbook of cold forming [M]. Leningrad: Mashinostroenie, 1971. (in Russian).

[8] Choudhury I.A., Lai O.H., Wong L.T. PAM-STAMP in the Simulation of Stamping Process of an Automotive Component [J]. Simulation Modeling Practice and Theory, 2006, 14: 71-81.

DOI: 10.1016/j.simpat.2005.04.002

[9] Solntsev Y.P. Metals and Alloys. Handbook [M]. St. -Petersburg: Professional, 2003. (in Russian).

[10] Eschea S.K., Ahmetoglu M.A., Kinzelc G.L., Altan T. Numerical and Experimental Investigation of Redrawing of Sheet metals [J]. Journal of Materials Processing Technology, 2000, 98(1): 17–24.

DOI: 10.1016/s0924-0136(99)00301-5

[11] Mouatassima M.E., Jameux J.P., Thomasa B., Mehrezc F., Milcentc G. The simulation of Multi-Operation Deep-Drawing Process at RENAULT with PAM STAMP [J]. Journal of Materials Processing Technology, 1994, 45(1-4): 317–322.

DOI: 10.1016/0924-0136(94)90359-x

[12] Hill R. The Mathematical Theory of Plasticity [M]. Oxford: Clarendon Press, (1950).

[13] Gronostajski Z. The Constitutive Equations for FEM Analysis [J]. Journal of Materials Processing Technology, 2000, 106: 40-44.

DOI: 10.1016/s0924-0136(00)00635-x
