Research on the Finite Element Simulation of the Laser Shock Forming of TC4 Titanium Alloy

Abstract:

laser shock forming, which combines the metal forming and material modification, is a non-mode, flexible forming new technology using laser-induced force effect of high amplitude shock waves to obtain the plastic deformation of sheet metal. in this paper, the simulation of laser shock forming process of tc4 sheet metal was carried out through the commercial finite element analysis software abaqus. the influence of the sheet thickness, laser energy, constraints aperture and laser spot spacing on the sheet metal deformation are investigated. the results show that: with the increase of sheet thickness, the deformation range of sheet decreases, and the amplitude of deformation decreases firstly and then increases. the deformation increases linearly with the increase of laser energy. the larger boundary constraint aperture leads to the larger deformation of sheet metal. there are no obvious influence on the forming accuracy when an opposite laser spot spacing is adopted. therefore, under the condition of meeting the accuracy requirement, for improving the efficiency, adopting a certain laser spot spacing to finish the forming should be considered.

You might also be interested in these eBooks

Advanced Materials and Manufacturing Technology II

View Preview

Info:

Periodical:

Key Engineering Materials (Volume 693)

Pages:

1121-1128

DOI:

https://doi.org/10.4028/www.scientific.net/KEM.693.1121

Citation:

Cite this paper

Online since:

May 2016

Authors:

Guo He Li*, David Mbukwa, Wei Zhao

Keywords:

Finite Element Analysis, Laser Shock Forming, TC4 Titanium Alloy

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

* - Corresponding Author

References

[1] J. Z. Zhou, J. C. Yan G, Y. K. Zhang Et Al. A Study on Super Speed Forming Of Metal Sheet by Laser Shock Waves. J. Mater. Process. Technol. 129 (2002) 241-244.

DOI: 10.1016/s0924-0136(02)00609-x

Google Scholar

[2] Zhou Jianzhong, Zhang Yongkang, Yang Jichang. Sheet Plastic Laser-Based Technology, Forming a Shock Wave of New Technology. Chinese Mechanical Engineering. 13 (2002) 1938-(1940).

Google Scholar

[3] Zhou Jianzhong, Zhang Yongkang, Liu Huixia Etc. Ld31 Sheet Deformation Experiments and Numerical Simulation of Pulsed Laser Shock. Laser. 24 (2004) 339-341.

Google Scholar

[4] Ji Weimin, Zhou Jianzhong, Yang Chaojun. Numerical Simulation and Finite Element Simulation of Sheet Deformation by Laser Shock. J. Trans. Chin. Soc. Agricul. Mach. 35 (2004) 171-174.

Google Scholar

[5] Zhang Yongkang, GAO Li. Numerical and Experimental Study of Laser Shock Deformation of Titanium Sheet. China Mechanical Engineering. 17 (2006) 1813-1816.

Google Scholar

[6] Gao Li. Experiments and Numerical Simulation of Laser Shock Forming For Stainless Steel. Laser. 28 (2008) 129-131.

Google Scholar

[7] Ding Hua, Wang Yun, CAI LAN. Laser Shock Forming Of Aluminum Sheet: Finite Element Analysis and Experimental Study. Appl. Surface. Sci. 256 (2010) 1703–1707.

DOI: 10.1016/j.apsusc.2009.09.098

Google Scholar

[8] Hua Ding, Ninggang Shen, Keqin Li Et Al. Experimental And Numerical Analysis Of Laser Peen Forming Mechanisms Of Sheet Metal. The 42nd North American Manufacturing Research Conference, Detroit, Michigan, Usa, June 9-13, (2014).

DOI: 10.1115/msec2014-4210

Google Scholar

[9] Meyer H W, Kleponis D S. Modeling the High Strain Rate Behavior of Titanium Undergoing Ballistic Impact and Penetration. Int. J. Impact. Eng. 26 (2001) 509-521.

DOI: 10.1016/s0734-743x(01)00107-5

Google Scholar
