An Experimental Research on the Vibration Reduction of Ball Bearings by Superfinishing Process

Abstract:

An experimental research on the reduction of vibration of ball bearings is provided in this paper. The waviness of inner race and outer race are decreased by superfinishing process, and their excitation frequencies are obtained. After the bearings’ vibration is tested, the powers of vibration distributed in different frequency regions are computed. The results reveal that the waviness excitations have a considerable influence on vibration of ball bearings in medium-frequency ranges, and the vibration can be reduced greatly by superfinishing process.

• Periodical: Key Engineering Materials (Volume 693)
• Pages: 1509-1516
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.693.1509
• Online since: May 2016
• Authors: Wen Tao Liu*, Yun Zhang, Zhi Jing Feng, Dong Feng Wang
• Keywords: Ball Bearing, Superfinishing, Vibration, Waviness

References

[1] T.E. Tallian, O.G. Gustafsson, Progress in rolling bearing vibration research and control, ASLE transactions 8 (3) (1965) 195 -207.

DOI: 10.1080/05698196508972094

[2] E. M. Yhland, Waviness Measurement-an instrument for quality control in rolling bearing industry, Proceedings of the Institution of Mechanical Engineers 182 (1967) 438-445.

DOI: 10.1243/pime_conf_1967_182_341_02

[3] L. D. Meyer, F. F. Ahlgren, B. Weichbrodt, An analytic model for ball bearing vibration to predict vibration response to distributed defects, Transactions of the American Society of Mechanical Engineers, Journal of Mechanical Design 102 (1980).

DOI: 10.1115/1.3254731

[4] F. P. Wardle, Vibration forces produced by waviness of the rolling surfaces of thrust loaded ball bearings part 1: theory, Proceedings of the Institution of Mechanical Engineers, Part C: Journal of Mechanical Engineering Science 202 (1988).

DOI: 10.1243/pime_proc_1988_202_127_02

[5] F. P. Wardle, Vibration forces produced by waviness of the rolling surfaces of thrust loaded ball bearings part 2: experimental validation, Proceedings of the Institution of Mechanical Engineers, Part C: Journal of Mechanical Engineering Science 202 (1988).

DOI: 10.1243/pime_proc_1988_202_128_02

[6] R. Savalia, M. K. Ghosh, R. K. Pandey, Vibration analysis of lubricated angular contact ball bearing of rigid rotor considering waviness of ball and races, Tribology Online 3 (6) (2008) 322-327.

DOI: 10.2474/trol.3.322

[7] S. Vafaei, H. Rahnejat, Indicated repeatable runout with wavelet decomposition (IRR-WD) for effective determination of bearing-induced vibration, Journal of Sound and Vibration 260 (2003) 67-82.

DOI: 10.1016/s0022-460x(02)00900-8

[8] C. S. Sunnersjö, Rolling bearing vibrations—the effects of geometrical imperfections and wear, Journal of Sound and Vibration 98 (4) (1985) 455-474.

DOI: 10.1016/0022-460x(85)90256-1

[9] C. K. Babu, N. Tandon, R. K. Pandey, Vibration modeling of a rigid rotor supported on the lubricated angular contact ball bearings considering six degrees of freedom and waviness on balls and races, Journal of Vibration and Acoustics 134 (2012).

DOI: 10.1115/1.4005140

[10] W. T. Liu, Y. Zhang, Z. J. Feng, J. S. Zhao, D. F. Wang, A study on waviness induced vibration of ball bearings based on signal coherence theory, Journal of Sound and Vibration 333 (2014) 6107-6120.

DOI: 10.1016/j.jsv.2014.06.040
