Development of Bevel Gear On-Machine Measurement System Based on Open CNC System

Abstract:

Bevel gear is a complicated curved surface parts, the traditional measuring method of bevel gear is by three coordinates measuring instrument for related parameters measurement and there are problems such as reload, high cost and waste of time. In this paper, development of Bevel gear on-machine measurement system based on open CNC system so that the manufacturing and measuring of bevel gear on the same machine tools. This article mainly has studied on structure and function of the system, analyzed the method of pitch deviation and the tooth surface error of the bevel gear and developed bevel gear on-machine measurement system by combining the method of MATLAB with VC++ mixed programming.
