Development and Validation of a Series Hybrid Electric Bulldozer Model on Whole Working Condition

Abstract:

Hybrid electric technology had been introduced into construction machinery from vehicle field. Hybrid electric bulldozer was focused by researchers recently. For constructing a simulation platform of the series tracked hybrid electric bulldozer on whole working condition, a model was built through the secondary development of ADvanced VehIcle SimulatOR (ADVISOR), which could simulate its performance on straight and steering working conditions. In the modeling process, bulldozer’s dynamics model, track walking mechanism model and oil pump model etc., were established and inserting by Matlab/Simulink. The field experiments were performed. The data from experiments and simulation outputs were compared to validate the correct of the model. The results showed that the operating parameters of model were in close proximity to those of experiments, which verifying the established model had significant high accuracy.

• Periodical: Key Engineering Materials (Volume 693)
• Pages: 1811-1817
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.693.1811
• Online since: May 2016
• Authors: Bao Di Zhang*, Xin Zhang, Liang Zhang, Li He Xi
• Keywords: Model, Series Hybrid Electric Bulldozer, Validation, Whole Working Condition

References

[1] Jong II Yoon, Dinh Quang Truong, Kyoung Kwan Ahn. A Generation Step for an Electric Excavator with a Control Strategy and Verifications of Energy Consumption [J]. International Journal of Precision Engineering and Manufacturing, 2013, 14(5): 755-766.

DOI: 10.1007/s12541-013-0099-6

[2] Sun Hui, Jing Junqing. Research on the system configuration and energy control strategy for parallel hydraulic hybrid loader [J]. Automation in Construction, 2010, 19: 213-220.

DOI: 10.1016/j.autcon.2009.10.006

[3] Song Qiang, Zeng Pu, Wang Hong. Study on power flowing control strategy of a series hybrid electric bulldozerr [J]. Transactions of Beijing Institute of Technology, 2014, 34(3): 267-272. (In Chinese with English abstract).

[4] Li Dongge, Zou Yuan, Liu Teng. Modeling and steering performance study of dual-motors independent driving tracked bulldozer[J]. Journal of Beijing Institute of Technology (English Edition), 2014, 23(12): 239-245.

[5] Zou Yuan, Chen Xiaoling, Li Dongge, et al. Parameter matching design and control optimization for series hybrid tracked bulldozer [J]. Journal of Mechanical Engineering, 2014, 50(1): 70-75. (In Chinese with English abstract).

DOI: 10.3901/jme.2014.01.070

[6] Wang Hong, Sun Fengcun. Dynamic modeling and simulation on a hybrid power system for dual motor-drive electric tracked bulldozer[C]/ Proceedings of the 2013 International Symposium on Vehicle, Mechanical, and Electrical Engineering, 2013: 229-233.

DOI: 10.4028/www.scientific.net/amm.494-495.229

[7] Yang Rong, Lou Diming, Pang Ran, et al. System modeling and performance simulation on series hybrid bulldozers[J]. Chinese Journal of Construction Machinery, 2012, 10(3): 280-285. (In Chinese with English abstract).
