Dynamic Characteristics Analysis and Structural Topology Optimization of the Plane Grinder

Abstract:

The dynamic characteristic is one of the important indicators which determine the performance of a machine tool, in this paper, the finite element model of a plane grinder is established with consideration of the behavior of joint, the static dynamic characteristics of machine tools are analyzed to reveal the vibration weak link, the column structure is topology optimized and redesigned based on the variable density degradation method. Static and dynamic characteristics of the original and new column are compared, and the dynamic characteristics of the machine tool before and after modification are discussed. The results indicate that the static and dynamic characteristics of the plane grinder are all improved after optimization.

• Periodical: Key Engineering Materials (Volume 693)
• Pages: 471-478
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.693.471
• Online since: May 2016
• Authors: Rui Tao Peng*, Wang Yan, Xin Zi Tang, Zhuan Zhou
• Keywords: Column, Dynamic Characteristics, FEM, Plane Grinder, Topology Optimization

References

[1] Wenjie Tan, Zhengxing Zuo, Yutong Liu, et al: Journal of Machine Design, Vol. 17 (2000) No. 1, p.24. (In Chinese).

[2] Liusheng Rao, Liang Hou, Yongjun Pan: Machine Design and Research, Vol. 26 (2010) No. 1-2, p.87. (In Chinese).

[3] Prager W: Computer Methods in Applied Mechanics and Engineering, Vol. 3 (1974) No. 3, p.349.

[4] Shijun Hu, Fu Zhang, Yang Den, Jian Han. Machinery and Electronics, 2011(9): 28-30. (in Chinese).

[5] Hongbo Zhang, Ruifeng Bo, Xiaohong You, et al: MACHINE TOOL and HYDRAULICS, Vol. 41 (2013) No. 2, p.150. (in Chinese).

[6] Yanlong Qiu. Manual Grinder Technicians [M]. Beijing: China Machine Press, 2002: 203. (in Chinese).
