3D Topography Analysis of Ball-End Milled H-13 Die Steel Surfaces Using Wavelet Decomposition Method

Abstract:

Optical profiler is employed to measure the surface topography of H-13 die steel machined by ball end cutter. By using 2D discret wavelet decomposition, the topographies of different frequency bands are obtained and the influence of cutter posture on varying frequncy bands topography is studied. The results show that cutter posture has a great influence on the whole frequency band roughness. The changing trend of roughness is roughly the same under different cutter postures which increase firstly then decrease with the decrease in frequency. A surface with a small high frequency roughness may have a large median frequency roughness.

• Periodical: Key Engineering Materials (Volume 693)
• Pages: 689-696
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.693.689
• Online since: May 2016
• Authors: Shuai Liu*, Jun Zhao, Xian Hua Tian, Wen Zhen Qin
• Keywords: Ball-End Milling, H-13 Die Steel, Wavelet Analysis

References

[1] D. Vakondios, P. Kyratsis, S. Yaldiz, et al: Measurement. Vol. 45(6) (2012), pp.1480-1488.

[2] M. Mhamdi, M. Boujelbene, E. Bayraktar, et al: Physics Procedia. Vol. 25 (2012), pp.355-362.

[3] T. Surmann, E. Krebs : Procedia CIRP. Vol. 2 (2012), pp.87-91.

[4] E. Krebs, P. Kersting : Procedia CIRP. Vol. 14 (2014), pp.366-370.

[5] X. Jiang, P. Scott, and D. Whitehouse : CIRP Annals - Manufacturing Technology. Vol. 57(1) (2008), pp.555-558.

[6] A.A.G. Bruzzone, J.S. Montanaro, A. Ferrando, et al: CIRP Annals - Manufacturing Technology. Vol. 53(1) (2004), pp.479-482.

[7] B. Josso, D.R. Burton and M.J. Lalor: Computer Methods in Applied Mechanics and Engineering. Vol. 191(8) (2001), pp.829-842.

DOI: 10.1016/s0045-7825(01)00292-4

[8] Q. Chen, S. Yang and Z. Li: Precision Engineering. Vol. 23(3) (1999), pp.209-212.

[9] M. Chen, Q. Pang, J. Wang, et al: International Journal of Machine Tools and Manufacture. Vol. 48(7-8) (2008), pp.905-913.
