Numerical Analysis of Reinforced Concrete Beam Strengthened with CFRP or GFRP Laminates

Abstract:

The behaviour of reinforced concrete beam strengthened with Carbon Fiber Reinforced Polymer (CFRP) and Glass fiber reinforced polymer GFRP laminates was investigated using finite element models and the results are presented in this paper. The numerical investigation assessed the effect of the configuration of FRP strengthening laminates on the behaviour of concrete beams. The load-deflection behaviour, and ultimate load of strengthened beam were compared to those of un-strengthened concrete beams. It was shown that using U-shaped FRP sheets increased the ultimate load. The stiffness of the strengthed beam also increased after first yielding of steel reinforcing bars. At was also observed that strengthening beams with FRP laminates to one-fourth of the beam span, modifies the failure of the beam from shear-controlled near the end of the unstrengthened beam, to flexure-controlled near mid-span. CFRP produced better results compared GFRP in terms of the ability to enhance the behavior of strengthenened reinforced concrete beams.

• Periodical: Key Engineering Materials (Volume 707)
• Pages: 51-59
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.707.51
• Online since: September 2016
• Authors: Osama Ahmed Mohamed*, Rania Khattab
• Keywords: Bond, CFRP, Concrete Beams, Finite Element Analysis (FEA), GFRP

References

[1] ANSYS – Release Version 11. A Finite Element Computer Software and User Manual for Nonlinear Structural Analysis, ANSYS 2007; Inc. Canonsburg, PA.

DOI: 10.1016/b978-0-12-811768-2.00022-5

[2] Amer M. Ibrahim, and M. Sh. Mahmood, Finite Element Modeling of Reinforced Concrete Beams Strengthened with FRP Laminates, European Journal of Scientific Research. 30 (4) (2009) 526-541.

[3] O.A. Mohamed, and R.M. Khattab, Numerical Analysis of Reinforced Concrete Beam Strengthened with CFRP Laminates, 1st International Conf. on Infrastructure Management, Assessment and Rehabilitation Techniques, ICIMART14, (2014).

[4] P. Jayajothi, R. Kumutha, and K. Vijai, Finite Element Analysis of FRP Strengthened RC Beams Using ANSYS., Asian Journal of Civil Engineering (BHRC), 14(4) (2013), 631-642.

[5] H.Y. Leung, Strengthening of RC Beams: Some Experimental Findings, Structural Survey, 20 (5), (2002) 173–181.

DOI: 10.1108/02630800210456823

[6] Sahar S. Choobbor , Flexural Performance Of Reinforced Concrete Beams Externally Strengthened With Carbon And Basalt FRP Sheets, MS Thesis, American University of Sharjah, College of Engineering, Sharjah, United Arab Emirates (2015).

DOI: 10.21474/ijar01/11206

[7] ACI 440. Report on Fiber-reinforced Polymer (FRP) Reinforcement for Concrete Structures, ACI 440. R-07. American Concrete Institute, (2007).

DOI: 10.14359/51663260

[8] M. R Esfahani, M.R. Kianoush, and A.R. Tajari, Flexural Behaviour of Reinforced Concrete Beams Strengthened by CFRP Sheets, Engineering Structures, 29 (10) ( 2007) 2428-2444.

DOI: 10.1016/j.engstruct.2006.12.008

[9] X. Lue, J. Teng, L. Ye and J. Jiang, Bond–slip models for FRP Sheets/Plates Bonded to Concrete, Engineering Structures, 27(6)(2005) 920–937.

DOI: 10.1016/j.engstruct.2005.01.014
