Degradation of Reinforced Concrete Structures of Aluminum Electrolysis Plants Subjected to Elevated Temperature and Cyclic Load

Abstract:

Technical papers describing the temperature related degradation of concrete are abundant, and serious damages often occurred in concrete structures subjected to high temperature such as metallurgy factories, although such occurrences were seldom made public. Concrete structures in aluminum electrolysis plants are generally subjected to high temperature emitted from electrolysis cells and cyclic load of heavy vehicles. Besides, hydrogen fluoride emitted from cells and stray current through reinforcement may cause deteriorating effects. In the case of an electrolysis plant built in Niigata in late 1960's, a part of passageway slab collapsed within a year of operation. A few years later, mesh shaped cracks on operation floor and shear cracks on floor beams and columns were observed. And an overall investigation on floor beams of 4 smelter buildings was carried out to determine the extent of deterioration, in 1972. The residual strength decreased linearly with operation term. The extent of strength reduction in "t" years' operation that we named "Deterioration Factor" and limit of lifetime were estimated. Countermeasures to reduce cyclic load and to reinforce floor beams were then taken, as well as the application of the Deterioration Factor to the next electrolysis plant in Shikoku Island. Details of renewed design of S-Electrolysis Plant and degradation of concrete are discussed. These aluminum electrolysis plants in Niigata and Shikoku have stopped operation in 1985 due to the withdrawal of the refining company, and existing smelter buildings have been diverted to another use. Although this paper presents rather retrospective cases, the authors wish this would be still helpful as a case study on degradation in concrete structure due to elevated temperature.

• Periodical: Key Engineering Materials (Volume 711)
• Pages: 533-540
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.711.533
• Online since: September 2016
• Authors: Hideo Kasami*, Takafumi Tayama
• Keywords: Aluminum Electric-Metallurgy, Compressive Strength, Destruction, Drilled Core, Fatigue, Shear Failure

References

[1] Japan Aluminum Society, Aluminum statistics in Japan, March 2007, Japan (in Japanese).

[2] Nakayama,I. et. al, A Small History of Aluminum Refining, Kallos Publishing, 1995, Japan.

[3] Miwa. H, Aluminum Industry in Japan - Prosperity and Decline of Japanese Aluminum Smelters, Mie University Press, 2016, Japan (in Japanese).

[4] Kvande. H., and Drabs.P. A., The Aluminum Smelting Process and Alternative Technologies, J. of Occupational and Environmental Medicine, Vol. 56, No. 4, pp.23-32, 2015 May. Norway.

[5] Kondoh M. "Challenge of Concrete to Severe Environment - Aluminum Electrolysis Plants and Concrete, Concrete Journal, Japan Concrete Institute, Vol. 17, No. 11, pp.28-30, Nov., 1979, Japan.

[6] Biczok I., Concrete Corrosion Protection, 1967, Chemical Publishing Company, USA.

[7] Kasami.H. Okuno, T. and Yamane S. Effects of Sustained Exposure to Elevated Temperatures up to 300C, Vol. H/5, Trans. of Int. Conf. SMirT-3rd, USA.

[8] D.J. Naus, The Effects of Elevated Temperature on Concrete Materials and Structures –A Literature Review, NUREG/CR-6900, ORNL/TH-10059, OakRidge National Laboratory, 2005, USA.
