Macrocell Corrosion Formation in Concrete Patch Repairs - A Laboratory Study

Abstract:

Corrosion of reinforcement steel bars is a major threat to the durability of concrete structures exposed to chloride contaminated environment. Patch repairing is widely practiced in affected structures to avoid further damage due to corrosion. Macrocell formation within the patch repair is identified as one main reason for the failure of patch repairs. In the present study, a group of patch repairing materials is tested for their potential to form macrocell corrosion after repaired in a chloride contaminated environment. The influence of parameters such as level of chloride contamination, type of repair materials and the area of steel bar receiving repair are presented based on macrocell current measurements. The selected repair materials for study were cement based, GGBS based and polymer based in its composition. It is found that the severity of macrocell depends on the driving potential existing between the repair and substrate concrete. The quality of substrate concrete and repair material influences the macrocell formation. The surface area of the steel bar that receives the repair also affects the macrocell current. The study will be used for the evaluation of repair materials for macrocell corrosion formation potential before their field application in a chloride contaminated environment.

• Periodical: Key Engineering Materials (Volume 711)
• Pages: 68-75
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.711.68
• Online since: September 2016
• Authors: Choorackal A. Eldho*, Ominda Nanayakkara, Jun Xia, Stephen W. Jones
• Keywords: Concrete Durability, Macrocell Corrosion, Patch Repair

References

[1] M. Raupach, Chloride-induced macrocell corrosion of steel in concrete - Theoretical background and practical consequences. Constr. Build. Mater. 10 (1996) 329–338.

DOI: 10.1016/0950-0618(95)00018-6

[2] B. Elsener, Macrocell corrosion of steel in concrete – implications for corrosion monitoring. Cem. Concr. Compos. 24 (2002) 65–72.

DOI: 10.1016/s0958-9465(01)00027-0

[3] D. R. Morgan, Compatibility of concrete repair materials and systems. Constr. Build. Mater. 10 (1996) 57–67.

[4] P. Gu, J. J. Beaudoin, P. J. Tumidajski, & N. P. Mailvaganam, Electrochemical incompatibility of patches in reinforced concrete. Concr. Int. 19 (1997) 68–72.

[5] J. Warkus & M. Raupach, Numerical modelling of macrocells occurring during corrosion of steel in concrete. Mater. Corros. 59 (2008) 122–130.

DOI: 10.1002/maco.200804164

[6] S. Qian, J. Zhang & Qu, D. Theoretical and experimental study of microcell and macrocell corrosion in patch repairs of concrete structures. Cem. Concr. Compos. 28 (2006) 685–695.

DOI: 10.1016/j.cemconcomp.2006.05.010

[7] Y. Ji, W. Zhao, M. Zhou, H. Ma, & Zeng, P. Corrosion current distribution of macrocell and microcell of steel bar in concrete exposed to chloride environments. Constr. Build. Mater. 47 (2013) 104–110.

DOI: 10.1016/j.conbuildmat.2013.05.003

[8] C. M. Hansson, A. Poursaee, & A. Laurent, Macrocell and microcell corrosion of steel in ordinary Portland cement and high performance concretes. Cem. Concr. Res. 36 (2006) 2098–2102.

DOI: 10.1016/j.cemconres.2006.07.005

[9] J. L. S. Ribeiro, Z. Panossian & S. M. S. Selmo, Proposed criterion to assess the electrochemical behavior of carbon steel reinforcements under corrosion in carbonated concrete structures after patch repairs. Constr. Build. Mater. 40 (2013) 40–49.

DOI: 10.1016/j.conbuildmat.2012.09.097

[10] American Society for Testing Materials. ASTM C 876-91: Standard Test Method for Half-Cell Potentials of Uncoated Reinforcing Steel in Concrete. in (1991).
