Study on Sensor Vibration Reduction Installation Structure with Damping Material of Ground Reflection Pressure Measurement

Abstract:

In blast field test, strong mechanical shock and vibration affect the output of blast pressure sensors. To avoid this phenomenon, a pressure sensor vibration reduction installation structure was designed for the measurements of ground reflection pressure. The damping material was used in the installation structure. And certain blast field test had been carried out. The data from the field blast test was compared to transducers with vibration reduction and transducers without vibration reduction. The results show that the obvious effect of the vibration reduction can eliminate vibration interference. And it is suitable for the measurements of shock wave over-pressure in blast field test.

• Periodical: Key Engineering Materials (Volume 730)
• Pages: 607-612
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.730.607
• Online since: February 2017
• Authors: Chen Li*, De Ren Kong, Shuang Ji Feng, Man Wang
• Keywords: Blast Field Test, Damping Material, Ground Reflection Pressure, Shock, Vibration, Vibration Reduction

References

[1] X. Tong. The research of shock wave pressure testing in blast field and the data processing method. Nanjing, Nanjing University of Science and Technology, (2015).

[2] Y. J. Li, J. Zu, D. M. Du. Generation and denoising of the vibration noise during shock wave test. Transduc. Microsyst. Tech. 29(8) (2010) 71-73.

[3] X. Wang, J. R. Huang, G. J. Sun. Experimental Study of An Isolation Measures in Pressure Measurement. J. Project. Rocket. Missile. Guidance, 33(6) (2010) 67-69.

[4] R. Wang, S. Q. Li, S. Y. Song. Research on Serialization Design Method of Rubber Vibration. Noise Vib. Contr. 4 (2006) 11-14.

[5] H. Y. Ren. The Application of Viscoelastic Damping Vibration Suppression for Shock-Isolation Structure of Multistage Missile. J. Astronaut. 28(6) (2007) 1494-1499.

[6] Y. L. Xue, D. G. Tang, D. P. Li, et al. Simulation of shock and vibration of nuclear explosion in limestone based on chemical explosion. Expl. Shock Wave. 35(2) (2015) 273-277.

[7] Q. Zhang, C. H. Bai, Q. M. Liu. Frequency Spectrum Characteristics of Explosion Earthquake Wave. J. Beijing Inst. Tech. 19(3) (1999) 46-48.

[8] W. G. Bi, C. Shi. Analysis on Frequency Factor in Structure Response Induced by Blasting Seismic Wave. Blast. 21(3) (2004) 87-89.

[9] Y. L. Huang, J. Q. Zhang. Experiment Study on the Blasting Dropping-vibration of Impacting the Ground. Blast. 20 (2003) 9-12.
