Features of the Process of Stretch Forming Shells Convex-Concave Shape

Abstract:

It is proposed to use actual computer software systems, providing a visualization and automation of the wrinkling and visualization and automation of the results of the numerical finite-element modeling of stretch forming a convex-concave shape in view of the fact that the saddle-backed surface of the shell has two families of asymptotic real straight lines. Along these lines, the saddle-backed surface of the shell with convex-concave shape is easy to break up or riffles are formed along them. The objectives of computer simulation are to predict unwanted distortion geometric form of the shell because of wrinkling and to find a ways to minimize the deviations of its surface deviations from the required shape.

You might also be interested in these eBooks

Advanced Materials and Processes of Metalworking II

View Preview

Info:

Periodical:

Key Engineering Materials (Volume 746)

Pages:

63-68

DOI:

https://doi.org/10.4028/www.scientific.net/KEM.746.63

Citation:

Cite this paper

Online since:

July 2017

Authors:

Vladimir A. Mikheev*, Sergey Surudin, Yaroslav A. Erisov, Ekaterina S. Khoruzhenko

Keywords:

Asymptotic Straight Lines, Generant a Saddle-Backed Surface, Manufacturing Method, Saddle-Backed Surface, Shell Convex-Concave Shape, Stretch Forming, Wrinkling
