Micro Milling on Thin Wire

Abstract:

Micro milling is discussed to fabricate micro-scale structures on titanium alloy thin wires. A machine tool was developed to conduct the milling operations with improving the clamping stiffness. A 0.3 mm diameter wire inserted into polyurethane tubes was clamped on an R-shaped groove on the machine table. The cutting tests were conducted with or without the polyurethane tube support. The machining shapes, the surface finishes and the cutting forces were measured to verify the effect of the polyurethane tube and machine table clamping system on stability in the cutting process. The groove direction is out of the feed direction of the end mill without the polyurethane tube support. The micro grooves are machined properly with a fine surface in the feed direction with the support. The cutting forces change periodically with the cutting thickness and the rotation of the cutter in milling. Non-symmetric grooves are also machined with the developed clamping system.

• Periodical: Key Engineering Materials (Volume 749)
• Pages: 81-86
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.749.81
• Online since: August 2017
• Authors: Masaki Serizawa, Takashi Matsumura*
• Keywords: Cutting Force, Micro Machining, Milling, Surface Finish

References

[1] L. J. Mishnaevsky, E. Levashov, R. Z. Valiev, J. Segurado, I. Sabirov, N. Enikeev, S. Prokoshkin, A. V. Solov'yov, A. Korotitskiy, E. Gutmanas, I. Gotman, E. Rabkin, S. Psakh'e,　L. Dluhos, M. Seefeldt, A. Smolin, Nanostructured titanium-based materials for medical implants: Modeling and development, Mater. Sci. and Eng. R, 81 (2014).

DOI: 10.1016/j.mser.2014.04.002

[2] A. K. Angirasa, M. J. Barrett, D. Silvester, SmartToe implant compared with kirschner wire fixation for hammer digi corrective surgery: A review of 28 patients, J. of Foot & Ankle Surgery, 51 (2012) 711–713.

DOI: 10.1053/j.jfas.2012.06.013

[3] G. Kaur, T. Willsmore, K. Gulati, I. Zinonos, Y. Wang, M. Kurian, S. Hay, D. Losic, A. Evdokiou, Titanium wire implants with nanotube arrays: A study model for localized cancer treatment, Biomaterials 101 (2016) 176-188.

DOI: 10.1016/j.biomaterials.2016.05.048

[4] M. Serizawa, M. Suzuki, T. Matsumura, 2015, Microthreading in Whirling, ASME J. of Micro- and Nano-Manufact., 3 (2015) 041001.

DOI: 10.1115/1.4030704

[5] M. Serizawa, T. Matsumura, Micro drilling on thin wire, Proc. of Int. Prec. Eng. Conf. 2016 (to be publish).

[6] M. A. Camara, J. C. Campos Rubio, A. M. Abrao, J. P. Davim, State of the Art on Micromilling of Materials, a Review, J. Mater. Sci. Technol., 28(8) 2012 673–685.

[7] T. Matsumura, Micromilling, in: Comprehensive Materials Processing, Reference Module in Materials Science and Materials Engineering, 11 (2014) 151-177, ISBN: 978-0-12-803581-8.

DOI: 10.1016/b978-0-08-096532-1.01106-7

[8] K. K. Singh, V. Kartik, R. Singh, Modeling dynamic stability in high-speed micromilling of Ti–6Al–4V via velocity and chip load dependent cutting coefficients, Int. J. of Mach. Tools & Manufact., 96 (2015) 56–66.

DOI: 10.1016/j.ijmachtools.2015.06.002

[9] T. Pratap, K. Patra, A. A. Dyakonov, Modeling cutting force in micro-milling of Ti-6Al-4V titanium alloy, Procedia Engineering, 129 (2015) 134–139.

DOI: 10.1016/j.proeng.2015.12.021

[10] T. Thepsonthi, T. Özel, Experimental and finite element simulation based investigations on micro-milling Ti-6Al-4V titanium alloy: Effects of cBN coating on tool wear, J. of Mater. Proc. Technol, 213 (2013) 532– 542.

DOI: 10.1016/j.jmatprotec.2012.11.003

[11] K. K. Singh, R. Singh, V. Kartik, Comparative study of chatter detection methods for high-speed micromilling of Ti6Al4V, Procedia Manufacturing, 1 (2015) 593-606.

DOI: 10.1016/j.promfg.2015.09.040

[12] I. Lazoglu, A. Mamedov, Deformation of thin parts in micromilling, CIRP Annals - Manufacturing Technology, (2016) (to be published).

DOI: 10.1016/j.cirp.2016.04.077
