Microscale Tests of Cement Paste Performed with FIB and Nanoindentation

Abstract:

This study deals with experimental determination of tensile properties of cement paste hydration products at micro-scale. Cantilever micro-beams with length of about 16 µm and pentagon cross section with micrometer dimensions were fabricated by focused ion beam milling on hydrated cement paste samples. Nanoindentation was used for evaluating elastic properties while tensile properties were derived from beam bending tests. Displacement controlled micro-scale tests give access to both tensile strength and estimates of fracture energy based on the load-displacement curves measured with the nanoindenter. The mean tensile strength and the fracture energy of inner hydration product were assessed as 791 MPa and 16.7 J/m², respectively. The huge difference of the micro-scale properties when compared to macroscopic values comes from the scaling properties of concrete.

• Periodical: Key Engineering Materials (Volume 760)
• Pages: 239-244
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.760.239
• Online since: January 2018
• Authors: Jiří Němeček*, Jiří Němeček
• Keywords: Cantilever Micro-Beam, Cement Paste, Focused Ion Beam, Fracture Energy, Nanoindentation, Tensile Strength

References

[1] J. Němeček, V. Králík, V. Šmilauer, L. Polívka, A. Jager, A Tensile strength of hydrated cement paste phases assessed by micro-bending tests and nanoindentation, Cement and Concrete Composites, 2016, 73(2016), 164-173. ISSN 0958-9465.

DOI: 10.1016/j.cemconcomp.2016.07.010

[2] L.A. Giannuzzi, F.A. Stevie, Introduction to Focused Ion Beams: Instrumentation, Theory, Techniques and Practice, Springer Science & Business Media, (2006).

DOI: 10.1007/b101190

[3] S. Reyntjens, R. Puers, A review of focused ion beam applications in microsystem technology, Journal of Micromechanics and microengineering, 2001, pp.287-300.

DOI: 10.1088/0960-1317/11/4/301

[4] W.C. Oliver, G.M. Pharr, An improved technique for determining hardness and elastic modulus using load and displacement sensing indentation experiments. Journal of Material Research 7, 1992, pp.1564-1583.

DOI: 10.1557/jmr.1992.1564

[5] J. Němeček, V. Hrbek, L. Polívka, A. Jager, Combined investigation of Low-scale Fracture in Hydrated Cement Assessed by Nanoindentation and FIB, In: 9th International Conference on Fracture Mechanics of Concrete and Concrete Structures, Fracture Mechanics for Concrete and Concrete Structures, 2016, pp.1-6.

DOI: 10.21012/fc9.244

[6] J. Němeček, V. Hrbek, Nanoindentation assessed fracture toughness of cement paste, In: Local Mechanical Properties. Curich: Trans Tech Publications, 2016, pp.186-189. Defect and Diffusion Forum. ISSN 1662-9507.

DOI: 10.4028/www.scientific.net/ddf.368.186

[7] C. Constantinides, F. -J. Ulm, The effect of two types of c-s-h on the elasticity of cement-based materials: results from nanoindentation and micromechanical modeling, Cement and Concrete Research 34, 2004, pp.67-80.

DOI: 10.1016/s0008-8846(03)00230-8

[8] J. Němeček, V. Králík, J. Vondřejc, Micromechanical analysis of heterogeneous structural materials, Cement & Concrete Composites 36, 2013, pp.85-92.

DOI: 10.1016/j.cemconcomp.2012.06.015

[9] G. Constantinides, F. -J. Ulm, The nanogranular nature of C-S-H, Journal of the Mechanics and Physics of Solids 55, 2007, pp.64-90.

[10] M. Bauchy, H. Laubie, M.A. Qomi, C. Hoover, F. -J. Ulm, R. -M. Pellenq, Fracture toughness of calcium-silicate-hydrate from molecular dynamics simulations, Journal of Non-Crystalline Solids 419, 2015, pp.58-64.

DOI: 10.1016/j.jnoncrysol.2015.03.031

[11] T. Ghebrab, P. Soroushian, Mechanical properties of hydrated cement paste: development of structure-property relationships, Journal of Concrete Structures and Materials 7, 2010, pp.37-43.

DOI: 10.4334/ijcsm.2010.4.1.037

[12] M. Hlobil, V. Šmilauer, G. Chanvillard, Micromechanical multiscale fracture model for compressive strength of blended cement pastes, Cement and Concrete Research 86, 2016, pp.188-202.

DOI: 10.1016/j.cemconres.2015.12.003
