Failures and Prediction Methods of Lateral Buckling Strength of H-Shaped Beams Connected by Flush End Plates

Abstract:

This paper presents boundary conditions for lateral buckling of the H-shaped beams connected to columns by flush end plates which fall into the lateral buckling following the out of plane plastic deformations of the flush end plates. The study is conducted by the following procedure: First, the behavior of the connection is researched by the no buckling experiment under the cyclic loading. As a result, it is found that the relationship between the out of plane plastic deformations of the endplates and the bending moment at the beam end can be predicted. Next, the FEM analyses of the rigid-frame structures consist of the slender beams having flush end plates connection and the structures consist of the beams having rigid connection are conducted to research the stress conditions in the tension flanges and the compression flanges of the beams during falling into lateral buckling. As a result, it is found that the rigid connection is restraining warping of the beam more tightly than the flush end plates connection, then the maximum bending moment strength against lateral buckling of the beams connected by rigid connections is higher than those of the beams connected by flush endplate. We recommend that the boundary conditions for the lateral buckling of the beams connected by flush end plates should be regarded to be different from those of the beams connected by the rigid connections.

• Periodical: Key Engineering Materials (Volume 763)
• Pages: 227-234
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.763.227
• Online since: February 2018
• Authors: Hiroshi Matsubara*, Junichi Takahashi, Yoshiharu Ikeguchi, Kikuo Ikarashi
• Keywords: Axial Force, Boundary Condition, Flush End Plate, H-Shaped Beam, Lateral Buckling Strength, Nonlinear FEM

References

[1] Recommendation for Design of Connections in Steel Structures, AIJ, (2012).

[2] Ben KATO, Hiroshi SAKUMA, Akiyoshi MUKAI: Maximum strength of bolted beam-to-column moment connection, Construction Engineering, AIJ, vol. 35B, 1989. 3.

[3] Takeshi NISHIMAKI, Daikou ITIOKA, Yasuhiro OHTANI: Effect of local behavior on rotational stiffness of semi-rigid connection with flush endplate, Summaries of Technical Papers of Annual Meeting, Architectural Institute of Japan, C-I, pp.629-630, (2006).

[4] Naoshi KUBO, Yoshinobu TANUMA, Kenichi HASHIMOTO: Cyclic Behaviors of Beam-to-Column Flush End Plate Connections, Summaries of Technical Papers of Annual Meeting, Architectural Institute of Japan, C-I, pp.443-444, (1998).

[5] Kenichi OHI, Seung-Jae LEE, Yuske SHIMAWAKI, Ruben GUZMAN: Hysteretic Behaviors of End-plate Connections Subjected to Earthquake Loading and Improvement on their Rotation Capacities, The Report of Institute of Industrial Science of The University of Tokyo, vol. 52-2, 2000. 2.

[6] Design of Joints in Steel and Composite Structures, ECCS (2016).

[7] Kikuo IKARASHI, Nobuyuki TOMO, Tao WANG: Effects of boundary conditions and end moment ratio on elastic lateral buckling strength of H-Shaped beams, Journal of Structural and Construction Engineering (Transactions of AIJ), Vol. 76, No. 670, pp.2173-2181.

DOI: 10.3130/aijs.76.2173

[8] Kikuo IKARASHI, Ryota SUEKUNI, Nobuyuki TOMO: Coupled buckling behavior and plastic deformation capacity of H-Shaped steel beams under cyclic bending shear, Journal of Structural and Construction Engineering (Transactions of AIJ), Vol. 77, No. 678, pp.1319-1328.

DOI: 10.3130/aijs.77.1319

[9] Recommendation for Limit State Design of Steel Structures, AIJ, (2010).

[10] Recommendations for the Plastic Design of Steel Structures, AIJ, (2010).
