Experimental Research on Electroforming Nano-ZrO₂ Reinforced Cu-Matrix Composite Aided by Pulse Power

Abstract:

Prepared the nanoZrO₂ reinforced Cu-matrix composite by pulse electroforming. The effects of the content of nanoZrO₂ particle in the casting solution, average cathodic current density, duty cycle, pulse frequency and ultrasonic power on the content of nanoZrO₂ in the electroforming Cu-matrix composite have been studied. The microhardness and surface morphology of Cu-ZrO₂ composite were analyzed. The experimental results demonstrate that the maximum content of nanoZrO₂ in the electroforming Cu-ZrO₂ composite is 2.94%, microhardness is 492 HV, which is significantly improved compared with pulse pure copper’s 337 HV, when the content of nanoZrO₂ is 40 g/L, average cathodic current density is 4A/dm², duty cycle is 0.2 , pulse frequency is 1100 Hz and ultrasonic power is 20w .The surface of composite prepared by pulse electroforming is more smooth, organization is denser, grain is finer and agglomeration of nanoZrO₂ particles is fewer compared with Direct-current electroforming nanoZrO₂ reinforced Cu-ZrO₂ composite.

• Periodical: Key Engineering Materials (Volume 764)
• Pages: 95-105
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.764.95
• Online since: February 2018
• Authors: Zhong Wen Sima*, Zhi Yong Li, Hong Bin Cui, Hun Guo
• Keywords: Cu-Matrix Composite, Nano-ZrO₂ Particles, Pulse Electroforming, Surface Morphology

References

[1] B.G. Zhu, Z.L. Wang, Development and application of electroforming technology, Electromachining & Mould, (2006) (5): 1-5.

[2] D. Zhu, The electrochemical principle, Beihang University Press, Beijing, (1999).

[3] H. Zhang, Z.C. Guo, X.Y. Han, Pulse electrodeposition RE-N-i W-P-SiC Composite coating technology, Mechanical engineering materials, 28(2004) (7): 29-34.

[4] J.Y. Fei, G.D. Wilcox, Electrodeposition of Zn-Co alloys with pulse containing reverse current, Electrochimica Acta. 50(2005): 2693-2698.

DOI: 10.1016/j.electacta.2004.11.014

[5] L.M. Chang, M.Z. An, H.F. Guo, et al., Microstructure and properties of N-i Co/nano-Al2O3 composite coatings by pulse reversal current electrodeposition, Applied Surface Science, 253(2006): 2132-2137.

DOI: 10.1016/j.apsusc.2006.04.018

[6] Z.W. ZHU, D. ZHU, N.S. QU, W.N. LEI, Pulse electroforming of nickel under perturbation of hard particles, Trans. Nonferrous Met. Soc. China, 15(2005) (3): 251- 254.

[7] E. G. Wolfgang, H.S. Hansal,  R. Mann,  M. Halmdienst,  J. Schalko,  F. Keplinger,  P. Svasek, Microgalvanic nickel pulse plating process for the fabrication of thermal microactuators, Microsystem Technologies, 20(2014)(4-5): 681-689.

DOI: 10.1007/s00542-013-2007-5

[8] W.N. LEI, D. Zhu, N.S. Qu, Synthesis of nano crystalline nickel in pulse deposition, Trans IMF , 80(2002)(6): 168- 171.

[9] N.S. Qu, D. Zhu, K.C. Chan, et al, Pulse electrodeposition of nano crystalline nickel using ultra narrow pulse width and high peak current density, Surface and Coatings Technology. 168(2003): 123- 128.

DOI: 10.1016/s0257-8972(03)00014-8

[10] S. Singh, S. Maheshwari, P. C. Pandey, Some investigations into the electric discharge machining of hardened tool steel using different electrode materials. Journal of Materials Processing Technology. 149(2004): 272-277.

DOI: 10.1016/j.jmatprotec.2003.11.046

[11] H.Y. Zheng, M.Z. An, Electrode position of Zn-Ni-Al2O3 nanocomposite coatings under ultrasound conditions, Journal of Alloys and Compounds. 459(2008): 548-552.

DOI: 10.1016/j.jallcom.2007.05.043

[12] K.P. WONG, K.C. CHAN, T.M. YUE, A study of hardness and grain size in pulse current electroforming of nickel using different shaped waveforms, Journal of Applied Electrochemistry. 31(2001): 25- 34.

[13] J.Y. FEI, G.Z. LIANG, W.L. XIN, Composition and Morphology of Zn-Co Alloy Coatings Deposited by Means of Pulse Plating Containing Reverse Current, Journal of Wuhan University of Technology. 3(2007): 417- 421.

DOI: 10.1007/s11595-006-3417-3

[14] A.R. Despic, K.I. Popov, Transport Controlled Deposition and Dissolution of Metals in Molten Aspects of Electrochemistry, Plenum Press, New York, (1972).

[15] A.R. Despic, K.I. Popov, Transport Controlled Deposition and Dissolution of Metals in Molten Aspects of Electrochemistry, (1972).

[16] F. Touyeras,  J.Y. Hihn,  X. Bourgoin,  B. Jacques,  L. Hallez,  V. Branger, Effects of ultrasonic irradiation on the properties of coatings obtained by electroless plating and electro plating, Ultrasonics Sonochemistry. 12(2004)(1-2): 9- 13.

DOI: 10.1016/j.ultsonch.2004.06.002
