Several Comments on Bearing Capacities of Selected Parts of Enclosure Walls from the Broumov Region

Abstract:

The Broumov group of churches was designed for the governing Benedictine abbey of St. Wenceslaw in Broumov by the famous Dientzenhofer family of architects, which helped define the Bohemian baroque style in the early 18th century. The paper shows numerical estimation of the bearing capacity. For the analysis were chosen the parts of enclosure walls from the selected Broumov Churches. The study summarizes the visual investigation and structural investigation using ATENA 2D software, to assess and verify the safety of the church walls regarding to the damages which currently suffers.

• Periodical: Key Engineering Materials (Volume 808)
• Pages: 15-26
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.808.15
• Online since: June 2019
• Authors: Pavel Kuklík*, Pratik Gajjar, Jacopo Scacco, Martin Valek
• Keywords: Compression Strength, FEM, Nonlinear Behavior, Nonlinear Fracture Mechanics, Plain Strain, Plain Stress, Simple Compression Test, Transversal Tension Limit

References

[1] B. Prokop, J. T. Kotalik and P. Suva, Broumov Group of Churches – Guide to Czech Baroque in the Landscape of Sandstone Rocks, Vernerovice: Modry Andel, (2007).

[2] M. Angelillo, P.B. Lourenço, G. Milani (2014) Masonry behavior and modelling. In: Angelillo M. (eds) Mechanics of Masonry Structures. CISM International Centre for Mechanical Sciences, vol 551. Springer, Vienna pp.1-26.

DOI: 10.1007/978-3-7091-1774-3_1

[3] EN 1990: Eurocode - Basis of structural design.

[4] Eurocode 6: Design of masonry structures.

[5] P. Gajjar, Nonlinear numerical evaluation of the wall bearing capacity and the structure stability of the St. Ann Church from the Broumov Group of Churches, Master Thesis, CR, Prague: Czech Technical University in Prague, (2018).

[6] J. Scacco, Nonlinear numerical evaluation of the wall bearing capacity and the structure stability of the St. Jacob Church from the Broumov Group of Churches, Master Thesis, CR, Prague: Czech Technical University in Prague, (2018).

[7] Proceq. 2012. Operating Instructions SilverSchmidt & Hammerlink. Proceq SA: Schwerzenbach.

[8] M. Drdacky et al. (2008). Compression tests on non-standard historic mortar specimens. HMC08 Historical Mortars Conference, Characterization, Diagnosis, Conservation, Repair and Compatibility.

[9] Lourenco, P. B. (2008). Structural masonry analysis: Recent developments and prospects. Proceedings of 14th International Brick and Block Masonry Conference (14IBMAC), 17- 20 February 2008, Sydney, Australia.

[10] Tarque, N., Benedetti, A., Camata, G., & Spacone, E. (2014). Numerical Modelling Of The In-PLane Behaviour Of Rubble Stone Masonry. SAHC2014_9th International Conference on Structural Anlysis of Historical Constructions. Mexico City.

[11] ICOMOS-ISCS. (2008). Illustrated glossary on stone deterioration patterns. ICOMOS.

[12] Labus, M. & Bochen, J. (2012) Sandstone degradation: an experimental study of accelerated weathering, Environ Earth Sci 67:7 (2027).

DOI: 10.1007/s12665-012-1642-y

[13] P. Reiterman, O. Holcapek, (2015). Deterioration of Different Sandstones Due to Freeze-Thaw Cycling. 53rd Conference on Experimental Stress Analysis 2015-06-01 Český Krumlov. Praha: Czech Technical University in Prague, 2015. s. 332-435.

[14] V. Cervenka, L. Jendele and J. Cervenka, ATENA Program Documentation Part 1: Theory, Prague: Cervenka Consulting, (2016).

[15] Ceska Geologicka Sluzba, Geologicka mapa,, [Online]. Available: http://mapy.geology.cz/geocr_50/. [Accessed June 2018].

[16] E. Susanti, Numerical evaluation of the bearing capacity of the All Saints Church walls in Broumov, Master Thesis, CR, Prague: Czech Technical University in Prague, (2017).

[17] Valek, J., Veiga, M. and Rosário, M. (2005). Characterisation of mechanical properties of historic mortars testing of irregular samples, STREMAH 2005 9th International Conference on Structural Studies, Repairs and Maintenance of Heritage Architecture, Msida, Malta.

[18] Circolare 2 febbraio 2009, n. 617 Istruzioni per l'applicazione delle «Nuove norme tecniche per le costruzioni» di cui al decreto ministeriale 14 gennaio (2008).
