Parameter Selection for Peel Strength Optimization of Thermoplastic CF-PA6 for Humm3^TM

Abstract:

For Automated Tape Placement process, degree of bond varies with variation in process parameters and material. Interlaminar bond strength characterization is one of the most important criteria in determining the quality of bond between two layers of thermoplastic tapes. Depending on the bond strength achieved using different process parameters, a process window is defined. Based on the process window an iterative procedure is adopted to find optimum parameters to realize maximum bond strength. This paper aims to investigate the interlaminar bond strength of thermoplastic CF-PA6, during Automated Tape Placement process. A fairly new heating source, a pulsed light solution, i.e. a humm3^TM system, which delivers uniform, highly controllable heat to the nip point is used. Experiments were conducted for different process parameters and results obtained using wedge peel test were analyzed. Results acquired help in assessing the material and the heating source in terms of capabilities and efficiency.

• Periodical: Key Engineering Materials (Volume 809)
• Pages: 297-302
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.809.297
• Online since: June 2019
• Authors: Neha Yadav*, Ralf Schledjewski
• Keywords: Automated Tape Placement, Interlaminar Bond Strength, Process Window

References

[1] M. A. Khan, P. Mitschang and R. Schledjewski, Parametric study on processing parameters and resulting part quality through thermoplastic tape placement process,, Journal of Composite Materials, vol. 47, no. 4, p.485–499, (2012).

DOI: 10.1177/0021998312441810

[2] S. Das, J. Warren and D. West, Global Carbon Fiber Composites Supply Chain Competitiveness Analysis,, NREL, (2016).

DOI: 10.2172/1260138

[3] Z. Qureshi, T. Swait, R. Scaife and H. M. El-Dessouky, In situ consolidation of thermoplastic prepreg tape using automated tape placement technology: Potential and possibilities,, Composites: Part B, vol. 66, pp.255-267, (2014).

DOI: 10.1016/j.compositesb.2014.05.025

[4] A. Khan, P. Mitschang and R. Schledjewski, Identification of Some Optimal Parameters to Achieve Higher Laminate Quality through Tape Placement Process,, Advances in Polymer Technology, vol. 29, no. 2, pp.98-111, (2010).

DOI: 10.1002/adv.20177

[5] W. J. B. Grouve, L. L. Warnet, B. Rietman and R. Akkerman, On the weld strength of in situ tape placed reinforcements on weave reinforced structures,, Composites: Part A, vol. 43, pp.1530-1536, (2012).

DOI: 10.1016/j.compositesa.2012.04.010

[6] R. Pitchumani, J. W. Gillespie Jr. and M. A. Lamontia, Design and Optimization of a Thermoplastic Tow-Placement with in-situ consolidation,, Journal of Composite Materials, vol. 31, no. 3, pp.244-275, (1997).

DOI: 10.1177/002199839703100302

[7] P. Monnot, D. Williams and M. D. Francesco, Power control of a flashlamp-based heating solution for Automated Dry Fibre Placement,, in ECCM 18, Athens, (2018).

[8] R. Schledjewski, Mechanical performance of in-situ consolidated thermoplastic fiber reinforced tape materials,, in ECCM 11, Rhodes, Greece, (2004).

[9] P. M. Schaefer, D. Gierszewski, A. Kollmannsberger, S. Zaremba and K. Drechsler, Analysis and improved process response prediction of laser- assisted automated tape placement with PA-6/carbon tapes using Design of Experiments and numerical simulations,, Composites: Part A, vol. 96, pp.137-146, (2017).

DOI: 10.1016/j.compositesa.2017.02.008

[10] J. Cheng, D. Zhao, K. Liu and Y. Wang, Process modeling and parameter optimization based on assumed inherent sensor inversion for composite automated placement,, Journal of Reinforced Plastics & Composites, vol. 36, no. 3, pp.226-238, (2017).

DOI: 10.1177/0731684416680456
