Viscosity-Temperature Characteristics and Application of High Borosilicate Glass

Abstract:

Viscosity-temperature characteristics of high borosilicate glass were investigated in detail by means of rotor viscometer and dilatometer. The neck-down deformation process of glass tube was simulated by Polyflow software, and the simulation was verified by the secondary drawing of glass perform. The results showed that the high temperature viscosity of borosilicate glass is higher compared to that of ordinary optical glass. In the high temperature stage, the fitting curves of VFT, AV, AG and MYEGA models are all in good agreement with the tested curve. However, in the low temperature stage, only viscosity fitted by VFT model is close to the tested value. Based on Navier-Stokes equation, a mathematical model of neck-down deformation of glass tube during secondary drawing is established. It is found that viscosity is the key material intrinsic factor affecting neck-down process of glass tube. The distribution of inner and outer diameters of glass tube along the drawing direction is simulated and analyzed under different feeding and drawing rates. The deviation between the steady-state dimension simulated and that actually drawn is only ±0.06 mm.

You might also be interested in these eBooks

Material Science and Engineering: Properties and Technologies

View Preview

Info:

Periodical:

Key Engineering Materials (Volume 837)

Pages:

125-132

DOI:

https://doi.org/10.4028/www.scientific.net/KEM.837.125

Citation:

Cite this paper

Online since:

April 2020

Authors:

Yan Hang Wang*, Tao Han, Kun He, Cheng Kui Zu

Keywords:

High Borosilicate Glass, Neck-Down, Secondary Drawing, Viscosity

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

* - Corresponding Author

References

[1] M.M. Limm, R. Monteiro. Thermochimica Acta Vol. 373 (2001), p.69.

Google Scholar

[2] Y. Q. Wang. Harbin Institute of Technology, China,(2010).

Google Scholar

[3] G. H. Frisehat，C. Muller-Fildebrandt and D. Moseler, et al. Journal of Non-Crystalline Solids Vol. 283 (2001), p.246.

Google Scholar

[4] P. Hrma, A. A. Kruger.. Journal of Non-Crystalline Solids Vol. 437 (2016), p.17.

Google Scholar

[5] B. Garza Montoya, L. M. Torres-Martnez and P. Quintana, et al.. Journal of Non-Crystalline Solids Vol. 329 (2003), p.22.

Google Scholar

[6] V.L. Wiesner, U.K. Vempati and N.P. Bansal. Scripta Materialia Vol. 124 (2016), p.189.

Google Scholar

[7] M. Chromčíková, M. Liška and J. Macháček, et al. Journal of Non-Crystalline Solids Vol. 401 (2014), p.237.

DOI: 10.1016/j.jnoncrysol.2014.01.021

Google Scholar

[8] P. Hrma. Journal of Non-Crystalline Solids Vol. 354 (2008), p.3389.

Google Scholar

[9] W. Zhu, M.A.T. Marple and M.J. Lockhart, et al. Journal of Non-Crystalline Solids Vol. 495 (2018), p.102.

Google Scholar

[10] K.M. Lee, Z.Y. Wei and Z. Zhou, et al. IEEE Transactions on Automation Science and Engineering Vol. 3 (2006), p.108.

Google Scholar

[11] X. Cheng, Y. Jaluria. International Journal of Heat and Mass Transfer Vol. 48 (2005), p.3560.

Google Scholar

[12] Z. Yin, Y. Jaluria. Journal of Heat Transfer Vol. 122 (2000), p.351.

Google Scholar

[13] D.F. Alistair, F. Kentaro and M.M. Tanya, et al. Journal of Lightwave Technology Vol. 19 (2001), p.(1924).

Google Scholar

[14] G. Hall, J.M. Watt. Oxford, U.K. Clareendon (1976), p.68.

Google Scholar

[15] S.R. Choudhury, Y. Jaluria. Journal of Materials Research Vol. 13 (1998), p.494.

Google Scholar
