Experimental Investigation of Steel Confinement of Clustered Large-Size Stud Shear Connector in Full-Depth Precast Bridge Deck Panel

Abstract:

The research focuses on investigating different types of steel confinements around a clustered large-size stud shear connector using in full-depth precast concrete bridge deck panel. The tests were based on Push-off test of two main groups of specimens: (1) the specimens with 4-stud shear connector where three different types of confinement were adopted including of O-ring confinement, Wire-mesh confinement, and L-angle confinement), and (2) the specimens with 8-stud shear connector where two different types of confinement were investigated including of Plate-ring confinement and L-angle confinement. The test results concluded that L-angle confinement type of the group of specimens with 4-Stud is the most sufficient type comparing between the different types of confinement in the same group. The maximum resistance was found at 41-ton, while as the displacement was found to be the most expansible and gradually reduced until the failure point. This means that the sign of failure can be noticeable prior to a collapse of the structure. For the group of specimens with 8-Stud, the resistance of this group was higher than the group of specimens with 4-Stud about 50 - 100% increase depending on each type of confinement. The maximum resistance was found for Plate-ring confinement type at 70-ton, which was agreed with the increment of the displacement about 20 - 50%. In comparison between specimens with 8-Stud, the Plate-ring confinement showed greater resistance and more relative displacement about 15% than the L-angle confinement.

• Periodical: Key Engineering Materials (Volume 856)
• Pages: 99-105
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.856.99
• Online since: August 2020
• Authors: Krissachai Sriboonma*, Sacharuck Pornpeerakeat
• Keywords: Clustered Stud, Large-Size Stud Connector, Precast Bridge Deck, Shear Connector, Steel Confinement

References

[1] S.S. Badie, M.K. Tadros, H.K. Kakish, D.L. Splittgerber, M.C. Baishya, Large Studs for Composite Action in Steel Bridge Girders, American Society of Civil Engineering (ASCE), J. Bridge Eng. 7(3) 2002 195-203.

DOI: 10.1061/(asce)1084-0702(2002)7:3(195)

[2] American Association of State Highway and Transportation Officials, AASHTO LRFD Bridge Design Specifications, (2012).

[3] T. Yamane, M.K. Tadros, S.S. Badie, M.C. Baishya, Full-Depth Precast Prestressed Concrete Bridge Deck System, PCI J. 43(3) 1998 50-66.

DOI: 10.15554/pcij.05011998.50.66

[4] Precast Concrete Institute on http://www.pci.org/design_resources/transportation_engineering_ resources/precast_bridge_decks.

[5] S.S. Badie, M.K. Tadros, A. Girgis, Full-Depth Precast Concrete Bridge Deck Panel Systems, NCHRP Report No. 12-65, Transportation Research Board, Washington, D.C. (2006).

DOI: 10.17226/25562

[6] K. Sriboonma, S.S. Sameh, Practical Steel Confinements for Widely Spaced Clustered Large Stud Shear Connectors in Composite Bridge Deck Panel Systems, NASCC, The Steel Conference and The Structures Congress, 12-15 May 2010, Florida, USA.

DOI: 10.1061/41130(369)289
