Evaluation of Carbon Nanotubes Asphalt Modification Using the Superpave Criteria

Abstract:

Rutting, fatigue cracking and low temperature cracking are the most important distresses in asphalt pavements as a result of changes in rheological properties of asphalt binder. Many types of modifiers were used to enhance asphalt behavior at both low and high temperatures. In this study, carbon nanotubes (CNT) were used as one of many nanomaterials that take a large attention in the latest research related to asphalt modification against different types of distresses. Effect of CNT on rheological properties of asphalt binder was investigated by testing unmodified and CNT modified asphalt binders using two of Superpave devices: Dynamic Shear Rheometer (DSR) and Bending Beam Rheometer (BBR). Penetration, softening point, flash point and rotational viscosity (RV) tests were carried out as well. CNT was added in 0.1%, 0.5% and 1% by weight of asphalt binder. It was found that adding CNT in 0.5% and 1% increase stiffness of asphalt and consequently asphalt pavement rutting resistance. On the other hand, this increase in stiffness affected pavement behavior adversely which is not desirable for fatigue and low temperature cracking. However, Superpave specifications were still satisfied and asphalt binder’s relaxation properties were improved upon CNT modification. It was eventually found that 0.5% of CNT is the optimum percentage for the best performance.

• Periodical: Key Engineering Materials (Volume 902)
• Pages: 135-143
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.902.135
• Online since: October 2021
• Authors: Mohammad Ali Khasawneh*, Khalid Ghuzlan, Nada Bani Melhem
• Keywords: Asphalt Modification, BBR, Carbon Nanotubes, DSR, PG Grading, Superpave

References

[1] Sureshkumar, M., Filipp, S., Polacco, G., Kazatchkov, I., Stastna, J. and Zanzotto, L. (2010). Internal structure and linear viscoelastic properties of EVA/asphalt nanocomposites. European Polymer Journal, 46(4), 621-633.

DOI: 10.1016/j.eurpolymj.2009.12.024

[2] Fang, C., Yu, R., Liu, S. and Li, Y. (2013). Nanomaterials Applied in Asphalt Modification: A Review. Journal of Materials Science and Technology, 29(7), 589-594.

DOI: 10.1016/j.jmst.2013.04.008

[3] Yao, H., You, Z., Li, L., Goh, S.W., Lee, C.H., Yap, Y.K. and Shi, X. (2013). Rheological properties and chemical analysis of nanoclay and carbon microfiber modified asphalt with Fourier transform infrared spectroscopy. Construction and Building Materials, 38 (January 2013), 327–337.

DOI: 10.1016/j.conbuildmat.2012.08.004

[4] El-Shafie, M., Ibrahim, I.M. and Abd El Rahman, A.M.M. (2012). The addition effects of macro and nano clay on the performance of asphalt binder. Egyptian Journal of Petroleum, 21,149-154.

DOI: 10.1016/j.ejpe.2012.11.008

[5] Pavement Interactive. (2008). Asphalt modifiers, (published 21 July 2008. https://www.pavementinteractive.org/article/materialsasphalt/, (accessed 24 October 2016).

[6] Polacco, G., Krˇízˇ, P., Filippi, S., Stastna, J., Biondi, D. and Zanzotto, L. (2008). Rheological properties of asphalt/SBS/clay blends. European Polymer Journal, 44 (11), 3512–3521.

DOI: 10.1016/j.eurpolymj.2008.08.032

[7] Abdullah, M., Zamhari, K., Buhari, R., Kamaruddin, N., Nayan, N., Hainin, M., Hassan, N., Jaya, R. and Yusoff, N. (2015). A Review on The Exploration of Nanomaterials Application in Pavement Engineering. Journal Technology (Sciences & Engineering), 73(4), 69–76.

DOI: 10.11113/jt.v73.4291

[8] Faramarzi, M., Arabani, M., Haghi, A. and Motaghitalab, V. (2013). A Study on the Effects of CNT's on Hot Mix Asphalt Marshal-Parameters. Proceeding of the 7th International Symposium on Advances in Science and Technology, Bandar-Abbas, Iran; 7-8 March, (2013).

[9] Dai, H. (2002). Carbon nanotubes: opportunities and challenges. Surface Science, 500(1-3), 218–241.

[10] Santagata, E., Baglieri, O., Tsantilis, L., Dalmazzo, D. (2012). Rheological Characterization of Bituminous Binders Modified with Carbon Nanotubes. Social and Behavioral Sciences, 53, 546 – 555.

DOI: 10.1016/j.sbspro.2012.09.905

[11] Shirakawa, T., Tada, A. and Okazaki, N. (2012). Development of Functional Carbon Nanotubes -Asphalt Composites. International Journal of GEOMATE, 2(1), 161-165.

DOI: 10.21660/2012.3.3q

[12] Xiao, F., Amirkhanian, A. and Amirkhanian, S. (2014). Long-term ageing influence on rheological characteristics of asphalt binders containing carbon nanoparticles. International Journal of Pavement Engineering, 12 (6), 533-541.

DOI: 10.1080/10298436.2011.560267

[13] Khattak, M., Khattab, A.and Rizvi, H. (2013). Characterization of carbon nano-fiber modified hot mix asphalt mixtures. Construction and Building Materials, 40, 738-745.

DOI: 10.1016/j.conbuildmat.2012.11.034

[14] Pirmohammad, S., Majd-Shokorlou, Y., & Amani, B. (2019). Experimental investigation of fracture properties of asphalt mixtures modified with Nano Fe2O3 and carbon nanotubes. Road Materials and Pavement Design, 1-23.

DOI: 10.1080/14680629.2019.1608289

[15] Sheng, X., Xu, T., & Wang, M. (2020). Preparation, shape memory performance and microstructures of emulsified asphalt modified by multi-walled carbon nanotubes. Construction and Building Materials, 230, 116954.

DOI: 10.1016/j.conbuildmat.2019.116954
