Powder Injection Moulding and Liquid Phase Sintering of Aluminium - SiC Particulate Composite

Abstract:

Metal matrix composite has been increasingly appreciated by many engineering applications due it its tailored properties for specific uses. Powder injection moulding is one of the most effective composite processing essentially for small and complex parts. Moulding of feedstock is the key step determining green and sintered properties. This research investigated effects of moulding parameters which are % solid loading and moulding speed on microstructure and properties of aluminium composite. Commercial aluminium alloy powder and SiC particulate at 15 vol.% addition were formulated at 55 % and 60 % solid loading. Injection moulding were operated using a horizontal screw driven typed machine at 1600-1800 rpm speed and 280 - 300 °C moulding temperature. After sintering at 655 °C, property assessment via microstructure, density, % shrinkage, distortion and hardness were carried out. It was found that feedstock of 55 % solid loading occasionally led to flash problem while that of higher solid loading experienced higher viscosity to fulfill four-cavity mould. Moulding speed investigated did not significantly affect mould filling and overall properties. Sintered microstructures generally showed well-distributed SiC particulate in the aluminium matrix. The optimum injection moulding condition was the feedstock prepared at 60% solid loading, moulding at 1800 rpm speed, which offered theoretical density of greater than 98.5 % and micro Vickers hardness of 125.2 H_v.

• Periodical: Key Engineering Materials (Volume 904)
• Pages: 213-220
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.904.213
• Online since: November 2021
• Authors: Tapany Patcharawit*, Phongsathon Thongbo, Nitithorn Sengna, Piyanat Auttachon, Nutthita Chuankrerkkul
• Keywords: Aluminium Composite, Moulding Parameters, Powder Injection Moulding, Silicon Carbide Reinforcement

References

[1] K. Shirvanimoghaddama, S.U. Hamim, M. K. Akbaric, S.M. Fakhrhoseini, H. Khayyam, A.H. Pakseresht, E. Ghasali, M. Zabete, K.S. Munir, S. Jia, J. P. Davim, M. Naebe, Carbon fiber reinforced metal matrix composites: Fabrication processes and properties. Composites Part A: Applied Science and Manufacturing, 92 (2017) 70-96.

DOI: 10.1016/j.compositesa.2016.10.032

[2] S. Pal, R. Mitra, V.V. Bhanuprasad, Aging behaviour of Al – Cu – Mg alloy – SiC composites, Materials Science and Engineering A 480 (2008) 496 – 505.

DOI: 10.1016/j.msea.2007.07.072

[3] C. Borgonovo, D. Apelian, M.M. Makhlouf, Aluminum nanocomposites for elevated temperature applications, Aluminum: Cast Shop and Alloy, Journal of Metal 63 (2011)57- 64.

DOI: 10.1007/s11837-011-0030-5

[4] S.O. Akinwamide, M. Lesufi, O.J. Akinribide, P. Mpolo, P. A. Olubambi, Evaluation of microstructural and nanomechanical performance of spark plasma sintered TiFe-SiC reinforced aluminium matrix composites, Journal of Materials Research and Technology 9 (2020) 12137-12148.

DOI: 10.1016/j.jmrt.2020.08.068

[5] M. Dyzia, Aluminum matrix composite (AlSi7Mg2Sr0.03/SiCp) pistons obtained by mechanical mixing method, Materials 11, 42 (2018).

DOI: 10.3390/ma11010042

[6] K.M.S. Manu, L.A. Raag, T.P.D. Rajan, M. Gupta, B.C. Pai, Liquid metal infiltration processing of metallic composites: a critical review, Metallurgical and Materials Transactions B 47 (2016) 2799 – 2819.

DOI: 10.1007/s11663-016-0751-5

[7] R.B. Bhagat, M.F. Amateau, J.C. Conway, Jr., J.M. Paulick, J.M. Chisholm, J.M. Parnell, D.G. Seidensticker, Squeeze Cast Metal Matrix Composites: Evaluation of their strength, damping capacity and corrosion resistance, Journal of Composite Materials 23 (1989) 961– 975.

DOI: 10.1177/002199838902300906

[8] F.A. Girot, R. FÉdou, J. M. Quenisset, R. Naslain, On the Squeeze Casting Conditions of Aluminum Matrix Composite Materials, Journal of Reinforced Plastic and Composites, 9 (1990) 456 – 469.

DOI: 10.1177/073168449000900503

[9] T. Sritharan, L.S. Chan, L.K. Tan, N. P. Hung, A feature of the reaction between Al and SiC particles in an MMC, Materials Characterization 47 (2001) 75 – 77.

DOI: 10.1016/s1044-5803(01)00144-9

[10] Ureña, E. E. Martínez, P. Rodrigo, L. Gil, Oxidation treatment for SiC particles used as reinforcement in aluminium matrix composite, Composite Science and Technology 64 (2004) 1843 – 1854.

DOI: 10.1016/j.compscitech.2004.01.010

[11] H. Ahamed, V. Senthilkumar, Experimental investigation on newly developed ultrafine-grained aluminium based nano-composites with improved mechanical properties, Materials & Design, 37 (2012) 182-192.

DOI: 10.1016/j.matdes.2011.12.036

[12] V.G. Dhore, W.S. Rathod, K.N. Patil, Investigation of mechanical properties of carbon nanotubes reinforced aluminium composite by metal injection molding, Materials Today: Proceedings 5 (2018) 20690 – 20698.

DOI: 10.1016/j.matpr.2018.06.452

[13] F. Ahmad, Orientation of short fibers in powder injection molded aluminum matrix composites, Journal of Materials Processing Technology, 169 (2005) 263 – 269.

DOI: 10.1016/j.jmatprotec.2005.03.036

[14] R.M. German, Sintering: from empirical observation to scientific principles, first ed., Butterworth – Heinemann, 2014. Chapter 9: Sintering with a liquid phase, 247 - 303.

DOI: 10.1016/b978-0-12-401682-8.00009-4

[15] T. Patcharawit, A. Ngeekoh, N. Chuankrerkkul, Phase evolution – property relationships of PIMed 5 - 40 vol.% SiCp – reinforced aluminium composite. IOP conf. series: Materials Science and Engineering 600 (2019) 012014.

DOI: 10.1088/1757-899x/600/1/012014

[16] A. Kimura, M. Shibata, K. Kondoh, Y. Takeda, M. Katayama, T. Kanie, H. Takada, Reduction mechanism of surface oxide in aluminum alloy powders containing magnesium studied by x-ray photoelectron spectroscopy using synchrotron radiation, Applied Physics Letters 70 (1997) 3615 – 3617.

DOI: 10.1063/1.119250

[17] J. Hashim, L. Looney, M.S.J. Hashmi, The wettability of SiC by molten aluminium alloy, Journal of Materials Processing Technology, 119 (2001) 324 – 328.

DOI: 10.1016/s0924-0136(01)00975-x

[18] R.M. German, A. Bose, Injection molding of metals and ceramics, first ed., Princeton, 1997, p.411.
