Microstructure and Phase Composition of the Cr-Mn-Fe-Co-Ni High-Entropy Alloy Obtained by Wire-Arc Additive Manufacturing

Abstract:

The work intends to study the microstructure, chemical and phase composition and homogeneity of chemical elements distribution in the Co-Cr-Fe-Mn-Ni high-entropy alloy produced via wire-arc additive manufacturing technology. The study has revealed three structure types in the alloy: (1) a smooth shagreen-type structure (an orange peel), which turns into a stripe-like structure (2) in some areas, and a grain structure (3) to appear as lengthy thin layers with the width of 50-80 μm and an average grain size of 12.5 μm, the most probable size of grains is detected to be in the range from 10 to 15 μm, a preferred number of such grains is 31%. The chemical composition of the produced alloy is assessed using X-ray microspectroscopy. The elements identified rank in descending order of concentration: Fe (38.88 wt. %), Co (26.08 wt. %), Ni (17.34 wt. %), Cr (14.33 wt. %), Mn (3.37 wt. %). The mapping of the alloy structure demonstrates the homogeneous and uniform distribution of chemical elements.

• Periodical: Key Engineering Materials (Volume 910)
• Pages: 748-753
• DOI: https://doi.org/10.4028/p-p2as1f
• Online since: February 2022
• Authors: Kirill Osintsev, Sergey Konovalov*, Victor Gromov, Dmitry Zaguyliaev
• Keywords: Chemical Composition, High-Entropy Alloy, Microstructure, Scanning Electron Microscopy, Wire-Arc Additive Manufacturing, X-Ray Microspectroscopy

References

[1] J.W. Yeh, S.K. Chen, S.J. Lin, J.Y. Gan, T.S. Chin, T.T. Shun, C.H. Tsau, S.Y. Chang, Nanostructured high-entropy alloys with multiple principal elements: Novel alloy design concepts and outcomes, Adv. Eng. Mater. 6 (2004) 299–303.

DOI: 10.1002/adem.200300567

[2] L.S. Zhang, G.L. Ma, L.C. Fu, J.Y. Tian, Recent Progress in High-Entropy Alloys, Adv. Mater. Res. 631–632 (2013) 227–232.

DOI: 10.4028/www.scientific.net/amr.631-632.227

[3] F. Průša, M. Cabibbo, A. Šenková, V. Kučera, Z. Veselka, A. Školáková, D. Vojtěch, J. Cibulková, J. Čapek, High-strength ultrafine-grained CoCrFeNiNb high-entropy alloy prepared by mechanical alloying: Properties and strengthening mechanism, J. Alloys Compd. 835 (2020).

DOI: 10.1016/j.jallcom.2020.155308

[4] S.J. Mary, R. Nagalakshmi, R. Epshiba, High Entropy Alloys Properties and Its Applications – an Overview, High Entropy Alloy. Sect. B-Review Eur. Chem. Bull. 4 (2015) 279–284.

[5] L. Cao, X. Wang, Y. Wang, L. Zhang, Y. Yang, F. Liu, Y. Cui, Microstructural evolution, phase formation and mechanical properties of multi-component AlCoCrFeNix alloys, Appl. Phys. A Mater. Sci. Process. 125 (2019) 1–11.

DOI: 10.1007/s00339-019-2959-0

[6] A. Vallimanalan, S.P.K. Babu, S. Muthukumaran, M. Murali, R. Mahendran, V. Gaurav, S. Manivannan, Synthesis, characterisation and erosion behaviour of AlCoCrMoNi high entropy alloy coating, Mater. Res. Express. 6 (2019).

DOI: 10.1088/2053-1591/ab4477

[7] M.C. Gao, P.K. Liaw, J.W. Yeh, Y. Zhang, High-entropy alloys: Fundamentals and applications, (2016).

[8] B. Cantor, I.T.H. Chang, P. Knight, A.J.B. Vincent, Microstructural development in equiatomic multicomponent alloys, Mater. Sci. Eng. A. 375–377 (2004) 213–218.

DOI: 10.1016/j.msea.2003.10.257

[9] S.J. Sun, Y.Z. Tian, H.R. Lin, X.G. Dong, Y.H. Wang, Z.J. Wang, Z.F. Zhang, Temperature dependence of the Hall–Petch relationship in CoCrFeMnNi high-entropy alloy, J. Alloys Compd. 806 (2019) 992–998.

DOI: 10.1016/j.jallcom.2019.07.357

[10] C. Li, Y. Xue, M. Hua, T. Cao, L. Ma, L. Wang, Microstructure and mechanical properties of AlxSi0.2CrFeCoNiCu1−x high-entropy alloys, Mater. Des. 90 (2016) 601–609.

DOI: 10.1016/j.matdes.2015.11.013

[11] T. Stasiak, S.N. Kumaran, M. Touzin, F. Béclin, C. Cordier, Novel Multicomponent Powders from the AlCrFeMnMo Family Synthesized by Mechanical Alloying, Adv. Eng. Mater. 21 (2019).

DOI: 10.1002/adem.201900808

[12] V. Dolique, A.-L. Thomann, P. Brault, Y. Tessier, P. Gillon, Thermal stability of AlCoCrCuFeNi high entropy alloy thin films studied by in-situ XRD analysis, Surf. Coatings Technol. 204 (2010) 1989–(1992).

DOI: 10.1016/j.surfcoat.2009.12.006

[13] P. Chen, C. Yang, S. Li, M.M. Attallah, M. Yan, In-situ alloyed, oxide-dispersion-strengthened CoCrFeMnNi high entropy alloy fabricated via laser powder bed fusion, Mater. Des. 194 (2020) 108966.

DOI: 10.1016/j.matdes.2020.108966

[14] D. Karlsson, A. Marshal, F. Johansson, M. Schuisky, M. Sahlberg, J.M. Schneider, U. Jansson, Elemental segregation in an AlCoCrFeNi high-entropy alloy – A comparison between selective laser melting and induction melting, J. Alloys Compd. 784 (2019) 195–203.

DOI: 10.1016/j.jallcom.2018.12.267

[15] J.W. Pegues, M.A. Melia, M.A. Rodriguez, T.F. Babuska, B. Gould, N. Argibay, A. Greco, A.B. Kustas, In situ synchrotron X-ray imaging and mechanical properties characterization of additively manufactured high-entropy alloy composites, J. Alloys Compd. 876 (2021) 159505.

DOI: 10.1016/j.jallcom.2021.159505

[16] H.R. Sistla, J.W. Newkirk, F. Frank Liou, Effect of Al/Ni ratio, heat treatment on phase transformations and microstructure of AlxFeCoCrNi2-x (x=0.3, 1) high entropy alloys, Mater. Des. 81 (2015) 113–121.

DOI: 10.1016/j.matdes.2015.05.027

[17] Y. Geng, S.V. Konovalov, X. Chen, Research Status and Application of the High-Entropy and Traditional Alloys Fabricated via the Laser Cladding, Usp. Fiz. Met. 21 (2020) 26–45.

DOI: 10.15407/ufm.21.01.026

[18] M. Cagirici, P. Wang, F.L. Ng, M.L.S. Nai, J. Ding, J. Wei, Additive manufacturing of high-entropy alloys by thermophysical calculations and in situ alloying, J. Mater. Sci. Technol. 94 (2021) 53–66.

DOI: 10.1016/j.jmst.2021.03.038

[19] B. Wu, Z. Pan, D. Ding, D. Cuiuri, H. Li, J. Xu, J. Norrish, A review of the wire arc additive manufacturing of metals: properties, defects and quality improvement, J. Manuf. Process. 35 (2018) 127–139.

DOI: 10.1016/j.jmapro.2018.08.001

[20] Q. Shen, X. Kong, X. Chen, Fabrication of bulk Al-Co-Cr-Fe-Ni high-entropy alloy using combined cable wire arc additive manufacturing (CCW-AAM): Microstructure and mechanical properties, J. Mater. Sci. Technol. 74 (2021) 136–142.

DOI: 10.1016/j.jmst.2020.10.037

[21] K.A. Osintsev, S.V. Konovalov, A.M. Glezer, V.E. Gromov, Y.F. Ivanov, I.A. Panchenko, R.V. Sundeev, Research on the structure of Al2.1Co0.3Cr0.5FeNi2.1 high-entropy alloy at submicro- and nano-scale levels, Mater. Lett. 294 (2021) 129717.

DOI: 10.1016/j.matlet.2021.129717

[22] V. Gromov, Y. Ivanov, S. Konovalov, K. Osintsev, A. Semin, Y. Rubannikova, Modification of high-entropy alloy AlCoCrFeNi by electron beam treatment, J. Mater. Res. Technol. 13 (2021) 787–797.

DOI: 10.1016/j.jmrt.2021.05.012

[23] E. Abbasi, K. Dehghani, Phase prediction and microstructure of centrifugally cast non-equiatomic Co-Cr-Fe-Mn-Ni(Nb,C) high entropy alloys, J. Alloys Compd. 783 (2019) 292–299.

DOI: 10.1016/j.jallcom.2018.12.329

[24] S.A. Firstov, T.G. Rogul', N.A. Krapivka, S.S. Ponomarev, V. V. Kovylyaev, N.I. Danilenko, N.D. Bega, V.I. Danilenko, S.I. Chugunova, Structural Features and Solid-Solution Hardening of High-Entropy CrMnFeCoNi Alloy, Powder Metall. Met. Ceram. 55 (2016) 225–235.

DOI: 10.1007/s11106-016-9797-9
