Experimental Study on the Local Behavior of CFRP Anchor Spikes Fixed to Masonry Substrates

Abstract:

An experimental investigation aimed to analyze the mechanical behaviour of Carbon Fiber Reinforced Composite (CFRP) anchor spikes inserted in a brick substrate is reported in this paper. As is well known, such devices can improve the structural performance of CFRP sheets externally bonded to masonry elements (as well as others substrate materials). In structural applications, spike anchors can be subjected to both shear and/or normal actions; the first commonly occurs in structural applications, while the latter may occur in specific applications, such as CFRP sheets bonded to curved surfaces. For this reason, the experimental program described in this paper analyzes the mechanical behavior of a typology of anchor spikes loaded (separately) by pure shear or normal actions. Although, obviously, in anchored CFRP sheet reinforcements the contribution to the bearing capacity of the sheet and of the anchors cannot be additively superimposed (the total capacity is of course not equal to the sum of the capacity of the sheet and of the anchor), the results described in this paper can still give useful indications in practical applications.

• Periodical: Key Engineering Materials (Volume 916)
• Pages: 361-368
• DOI: https://doi.org/10.4028/p-26f38r
• Online since: April 2022
• Authors: Mario Fagone*, Tommaso Rotunno, Elisa Bertolesi, Ernesto Grande, Gabriele Milani
• Keywords: CFRP Reinforcements, Experimental Tests, Masonry, Spike Anchor

References

[1] M.R. Valluzzi, D. V Oliveira, A. Caratelli, G. Castori, M. Corradi, G. de Felice, E. Garbin, D. Garcia, L. Garmendia, E. Grande, U. Ianniruberto, A. Kwiecien, M. Leone, G.P. Lignola, P.B. Lourenco, M. Malena, F. Micelli, M. Panizza, C.G. Papanicolaou, A. Prota, et al., Round Robin Test for composite-to-brick shear bond characterization, Mater. Struct., 45 (2012) 1761–1791.

DOI: 10.1617/s11527-012-9883-5

[2] T.C. Triantafillou, Strengthening of masonry structures using epoxy-bonded FRP laminates, J. Compos. Constr., 2 (1998) 96–104.

DOI: 10.1061/(asce)1090-0268(1998)2:2(96)

[3] P. Foraboschi, Effectiveness of novel methods to increase the FRP-masonry bond capacity, Compos. Part B Eng., 107 (2016) 214–232.

DOI: 10.1016/j.compositesb.2016.09.060

[4] D. V. Oliveira, I. Basilio, P.B. Lourenço, Experimental Bond Behavior of FRP Sheets Glued on Brick Masonry, J. Compos. Constr., 15 (2011) 32–41.

DOI: 10.1061/(asce)cc.1943-5614.0000147

[5] C. Caggegi, V. Pensee, M. Fagone, M. Cuomo, L. Chevalier, Experimental global analysis of the efficiency of carbon fiber anchors applied over CFRP strengthened bricks, Constr. Build. Mater., 53 (2014) 203–212.

DOI: 10.1016/j.conbuildmat.2013.11.086

[6] M. Fagone, G. Ranocchiai, C. Caggegi, S. Briccoli Bati, M. Cuomo, The efficiency of mechanical anchors in CFRP strengthening of masonry: An experimental analysis, Compos. Part B. Eng., 64 (2014) 1–15.

DOI: 10.1016/j.compositesb.2014.03.018

[7] T. Rotunno, M. Fagone, E. Bertolesi, E. Grande, G. Milani, Curved masonry pillars reinforced with anchored CFRP sheets: An experimental analysis, Compos. Part B Eng., 174 (2019).

DOI: 10.1016/j.compositesb.2019.107008

[8] M. Fagone, G. Ranocchiai, S. Briccoli Bati, An experimental analysis about the effects of mortar joints on the efficiency of anchored CFRP-to-masonry reinforcements, Compos. Part B-Engineering, 76 (2015) 133–148.

DOI: 10.1016/j.compositesb.2015.01.050

[9] E. Grande, M. Fagone, T. Rotunno, E. Bertolesi, G. Milani, Modelling of the bond behaviour of curved masonry specimens strengthened by CFRP with anchor spikes, Compos. Part B Eng., 171 (2019) 235–245.

DOI: 10.1016/j.compositesb.2019.04.027

[10] E. Bertolesi, G. Milani, M. Fagone, T. Rotunno, E. Grande, Heterogeneous FE model for single lap shear tests on FRP reinforced masonry curved pillars with spike anchors, Constr. Build. Mater., 258 (2020) 119629.

DOI: 10.1016/j.conbuildmat.2020.119629

[11] T. Rotunno, M. Fagone, E. Bertolesi, E. Grande, G. Milani, Single lap shear tests of masonry curved pillars externally strengthened by CFRP strips, Compos. Struct., 200 (2018) 434–448.

DOI: 10.1016/j.compstruct.2018.05.097

[12] M. Fagone, T. Rotunno, E. Bertolesi, E. Grande, G. Milani, An experimental study on the effectiveness of cfrp reinforcements applied to curved masonry pillars, in: A. Carcaterra, A. Paolone, G. Graziani (Eds.), Lect. Notes Mech. Eng., Springer, Cham, Rome, 2020: p.2134–2148.

DOI: 10.1007/978-3-030-41057-5_170

[13] T. Rotunno, M. Fagone, E. Bertolesi, E. Grande, G. Milani, Some considerations about the effects of the bonding length on the effectiveness of spike anchors in cfrp reinforcements of masonry, Key Eng. Mater., 817 KEM (2019) 141–148.

DOI: 10.4028/www.scientific.net/kem.817.141
