Study on Plan Magnetic Abrasive Finishing - Discussion on Processing Methods for Improving Flatness

Abstract:

Magnetic abrasive finishing (MAF) is a precision surface polishing method. At present, most studies on planar MAF are focused on improving the surface roughness accuracy and the uniformity of roughness. In practical applications, the initial surface of the work piece is not only a rough surface, but also a flat surface without a uniform height. While the traditional processing method improves the surface roughness accuracy, the original surface is basically unchanged. In this paper, a processing method is studied. According to the uneven distribution of magnetic brushes, the reasonable distribution of processing speed and processing time can finally achieve the purpose of improving the surface flatness. At the same time, this paper analyzes the non-uniform characteristics of the magnetic pole and the magnetic brush itself, and verifies the effectiveness of the processing method through experiments.

• Periodical: Materials Science Forum (Volume 1018)
• Pages: 123-128
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.1018.123
• Online since: January 2021
• Authors: Yu Long Zhang, Yan Hua Zou*, Hui Jun Xie
• Keywords: Flatness, Magnetic Abrasive Finishing, Surface Morphology, Uniform Speed Processing, Variable Speed Processing

References

[1] N.K. Jain, V.K. Jain, S.Jha, Parametric optimization of advanced fine-finishing processes, Int. J. Adv. Manuf. Technol. 34(2007) 1191–1213.

DOI: 10.1007/s00170-006-0682-4

[2] H. J.Xie, Y. H.Zou, C. W. Dong, J. Z. Wu, Study on the magnetic abrasive finishing process using alternating magnetic field: investigation of mechanism and applied to aluminum alloy plate, Int. J. Adv. Manuf. Technol. 102(5-8)(2019)1509-1520.

DOI: 10.1007/s00170-018-03268-8

[3] T.Shinmura, K.Takazawa, E.Hatano, M.Matsunaga, T.Matsuo, Study on Magnetic Abrasive Finishing, CIRP Annals 39(1)(1990)325-328.

DOI: 10.1016/s0007-8506(07)61064-6

[4] B. Gupta, A. Jain, R.Purohit, R.S. Rana, B. Gupta, Effects of process parameters on the Surface Finish of Flat Surfaces in Magnetic assist Abrasive Finishing Process, Materials Today: Proceedings 5 (2018) 17725–17729.

DOI: 10.1016/j.matpr.2018.06.095

[5] Rahul S. Mulik, Pulak M. Pandey. Ultrasonic assisted magnetic abrasive finishing of hardened AISI 52100 steel using unbonded SiC abrasives[J]. International Journal of Refractory Metals and Hard Materials,2010,29(1).

DOI: 10.1016/j.ijrmhm.2010.08.002

[6] A. Y. Jiao,H. J. Quan,Z. Z. Li,Y. H. Zou. Study on improving the trajectory to elevate the surface quality of plane magnetic abrasive finishing[J]. The International Journal of Advanced Manufacturing Technology,2015,80(9-12).

DOI: 10.1007/s00170-015-7136-9

[7] Y. H.Zou, A. Y. Jiao,Toshio Aizawa. Study on Plane Magnetic Abrasive Finishing Process - Experimental and Theoretical Analysis on Polishing Trajectory -[J]. Advanced Materials Research,2010,984.

DOI: 10.4028/www.scientific.net/amr.126-128.1023

[8] Y. H.Zou, H. J.Xie, C. W.Dong, J. Z.Wu, Study on complex micro surface finishing of alumina ceramic by the magnetic abrasive finishing process using alternating magnetic field, Int. J. Adv. Manuf. Technol. 97(5-8)(2018)2193-2202.

DOI: 10.1007/s00170-018-2064-0
