Analytical Modeling of Cutting Forces and Technological Parameters Interrelation when Grinding Shafts' Ends by a Grinding Wheel End on Circular Grinding Machines

Abstract:

Abrasive processing remains one of most demanded for hardened steels parts. Grinding of end surfaces of machines parts has become widespread due to the fact that it allows processing heat-treated surfaces more efficiently than turning and also correcting the surface geometry. This processing type is used almost mainly for finish processing operations of shafts ends, bearing rings, gears, etc. However, there is still no mathematical model for this processing type, which would satisfy most of the main technological parameters. In this article a mathematical model of the cutting force when grinding the shaft end by the grinding wheel end on circular grinding machines is obtained. Processing schemes for this grinding type are given and the calculated graph of the cutting force according to the obtained mathematical model is shown.

• Periodical: Materials Science Forum (Volume 1037)
• Pages: 377-383
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.1037.377
• Online since: July 2021
• Authors: Sergey Yudin*, Pavel Pereverzev, Boris Reshetnikov
• Keywords: Circular Grinding Machines, Ends' Grinding by a Grinding Wheel End, Metals Grinding

References

[1] S. Yudin, K. Smolyanoy, P. Pereverzev, Generalized cutting force model for grinding, IOP Conference Series: Materials Science and Engineering, vol. 709 (2020) 03300.

DOI: 10.1088/1757-899x/709/3/033005

[2] Pereverzev, P. P. Popova, A. V. Analytical simulation of the relations between the cutting force and the basic processing parameters during internal grinding, Metalloobrabotka, No. 3 (75) (2013).

[3] Pereverzev, P. P. Modelling and optimizing controlling software for automated machine production in Bulletin of South Ural State University. Series: Mechanical Engineering Industry, Issue 12 (271) (2012) 152-157.

[4] Pereverzev, P. P. Modelling processing restrictions during the optimization of automated grinding cycles in Bulletin of South Ural State University. Series: Mechanical Engineering Industry. 2012. Issue 12 (271). P. 165-168.

[5] Korchak, S. N. Theoretical bases of processing parameter impact on the efficiency improvement of steel part grinding: thesis for the doctoral degree in engineering. Chelyabinsk, 1973, 372 p.

[6] Korchak, S. N. Theoretical bases of processing parameter impact on the efficiency improvement of steel part grinding: thesis for the doctoral degree in engineering. 05.02.08 by Korchak Stanislav Nikolayevich. Chelyabinsk, 1973, 345 p.

[7] Korchak, S. N. Steel part grinding efficiency by S. N. Korchak. Moscow: Mashinostroyeniye, 1974, 297с.

[8] Maslov, Ye. N. The theoretical bases of metal grinding. Moscow: Mashgiz, 1951, 190 p.

[9] Lurye, G. B. Metal grinding. Moscow: Mashinostroyeniye, 1969, 176 p.

[10] Tergan, V. S., Liberman, B. S. Plane grinding. Moscow: Vysshaya Shkola, 1969, 284 p.

[11] Tergan, V. S., Torgan, A. V. A young grinder's reference book on plane grinding. Moscow: Vysshaya Shkola, 1975. 215 p.

[12] Cutting modes for works performed on manual and semi-automated grinding and finishing machines: reference book by D. V. Ardashev [et al.]. — Chelyabinsk: ATOKSO, 2007, 384 p.
