Stress Simulation of the Structure of a Stretch Die Made by Fused Deposition Modeling

Abstract:

The paper is devoted to the assessment of the possibility to use a new design of a stretch die made of plastics used for fused deposition modeling (FDM) 3 D printing. Studies were conducted to assess the stress-strain state of a stretch die, from the normal pressure of a deforming sheet blank in a NASTRAN solver, using the finite element method. The convergence assessment of the simulation results was carried out for different quantities and corresponding sizes of finite elements. The optimal thicknesses of the hollow structure of the stretch die were determined by step-by-step calculations of its stress-strain state for acrylonitrile butadiene styrene (ABS) and polyethylene terephthalate glycol (PETG). On the basis of the conducted studies, a general algorithm was developed for the structural design of stretch dies made of plastics used for fused deposition modeling (FDM) printing.

• Periodical: Materials Science Forum (Volume 1037)
• Pages: 47-54
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.1037.47
• Online since: July 2021
• Authors: Anastasia O. Koshkina*, Evgeny G. Karpukhin, Alexander V. Morozov, Alexander E. Abramov
• Keywords: Convergence Assessment, Design Algorithm, Finite Element Analysis (FEA), Fused Deposition Modeling (FDM), Stretch Die, Stretch Forming

References

[1] M.N. Gorbunov, Technology of stamping works in the production of aircraft, Moscow, (1981).

[2] P.J. Blau, Friction science and technology: from concepts to applications. 2nd ed., (2009).

[3] E. G. Karpukhin, A. O. Koshkina, Evaluation of the antifriction properties of the coatings stretch-forming dies for use in stretch-forming panels on the stretch-forming machines FET and FEL, XXIV Tupolev Readings (School of young scientists), (2019) 427-431.

DOI: 10.18411/lj-04-2019-238

[4] V.S. Bogolyubov, Forming equipment made of polymer materials, Moscow, (1979).

[5] A. E. Shkuro, Technology and materials for 3D-printing, Krivonogov, Yekaterinburg, (2017).

[6] Workplace instructions 1.4.1854-88. The technology of forming the skins by the method of longitudinal stretch-forming on RO type stretch-forming machines. Moscow, (1989).

[7] Information on https://dielectricmfg.com/knowledge-base/.

[8] Information on https://www.engineersedge.com/plastic/materials_common_plastic.htm.

[9] Anastasia Koshkina, Alexander Fedorov, Alexander Morozov, Evgeny Karpukhin, Yulia Poletaeva, The study of the FDM technology of 3D printing with the use of materials for production tooling, MATEC Web of Conferences 329, (2020) 03068.

DOI: 10.1051/matecconf/202032903068
