Ethyl Cellulose/SiO₂ Composite Microencapsulated Red Phosphorus: An Efficient Flame Retardant for Epoxy Resin

Abstract:

At present, the shell structures of the microencapsulated red phosphorus (RP) are mostly derived from petroleum materials and possess certain toxicity, which may do potential harm to the human beings and environment during preparation process. To solve this problem, the bio-based ethyl cellulose (EC) was selected as the shell material for microencapsulated RP in this work. Meanwhile, combining the anti-solvent and sol-gel methods in one pot, the EC/SiO₂ shell structure was prepared by one step for the first time. The characterization results verified the fabrication of the integrated EC and EC/SiO₂ shell structures. Meanwhile, the thermogravimery analysis indicated that the EC/SiO₂ shell structure significantly improved the thermal stabilty and char-forming ability of pristine RP. The flame retardance of RP, EC coated RP (RP@EC) and EC/SiO₂ coated RP (RP@EC/SiO₂) on epoxy resin (EP) was investigated by cone calorimeter tests. The results showed that EP blending with 7 wt% RP@EC/SiO₂ (EP/RP@EC/SiO₂) decreased the heat release rate (HRR) and total heat release rate (THR) of neat EP by 55.65% and 30.11%, respectively. The char residuals after cone calorimeter tests were tested by scanning electron microscope and X-ray diffraction. The results showed that EP/RP@EC/SiO2 composites fabricated char residuals with continuous structures during the burning process, and the amorphous SiO₂ in the char residuals was supposed to further improve the thermal insulation property. The compact and thermostable char residuals formed during cone calorimeter tests led to the superior flame retardance of RP@EC/SiO₂.

• Periodical: Materials Science Forum (Volume 1060)
• Pages: 29-35
• DOI: https://doi.org/10.4028/p-a9mgkj
• Online since: May 2022
• Authors: Chen Cheng, Yan Lling Lu, Shi Guo Du*
• Keywords: Epoxy Resin, Ethyl Cellulose, Red Phosphorus, Silicone Dioxide

References

[1] S. Yang, J. Wang, S. Q. Huo, L. F. Cheng, M. Wang, Preparation and flame retardancy of an intumescent flame-retardant epoxy resin system constructed by multiple flame-retardant compositions containing phosphorus and nitrogen heterocycle, Polym. Degrad. Stab. 119 (2015) 251-259.

DOI: 10.1016/j.polymdegradstab.2015.05.019

[2] W. M. Qian, M. H. Vahid, Y. L. Sun, A. Heidari, R. B. Isfahani, S. S. Samandari, A. Khandan, D. Toghraie, Investigation on the effect of functionalization of single-walled carbon nanotubes on the mechanical properties of epoxy glass composites: Experimental and molecular dynamics simulation, J MATER RES. 12 (2021) 1931-1945.

DOI: 10.1016/j.jmrt.2021.03.104

[3] M. Kim, H. Ko, S. M. Park, Synergistic effects of amine-modified ammonium polyphosphate on curing behaviors and flame retardantion properties of epoxy composites, Compos. Part B. 170 (2019) 19-30.

DOI: 10.1016/j.compositesb.2019.04.016

[4] M. Dogan, S. Murat Unlu, Flame retardant effect of boron compounds on red phosphorus containing epoxy resins, Polym. Degrad. Stab. 99 (2014) 12–17.

DOI: 10.1016/j.polymdegradstab.2013.12.017

[5] R. K. Jian, L. Chen, Z. Hu, Y. Z. Wang, Flame-retardant polycarbonate/acrylonitrile-butadiene-styrene based on red phosphorus encapsulated by polysiloxane: Flame retardance, thermal stability, and water resistance, J. Appl. Polym. Sci. 123 (2012) 2867-2874.

DOI: 10.1002/app.34845

[6] S. K. Chang, C. Zeng, W. Z. Yuan, J. Ren, Preparation and characterization of double-layered microencapsulated red phosphorus and its flame retardance in poly(lactic acid), J. Appl. Poly. Sci. 125 (2012) 3014-3022.

DOI: 10.1002/app.36449

[7] Z.-J. Cao, X. Dong, T. Fu, S.-B. Deng, W. Liao, Y.-Z. Wang, Coated vs. Naked red phosphorus: a comparative study on their fire retardancy and smoke suppression for rigid polyurethane foams, Polym. Degrad. Stab. 136 (2017) 103–111.

DOI: 10.1016/j.polymdegradstab.2016.12.004

[8] Galina F. Levchik, Svetlana A. Vorobyova, Viktoria V. Gorbarenko, Sergei V. Levchik, Some mechanistic aspects of the fire retardant action of red phosphorus in aliphatic nylons, J. Fire Sci. 18 (2000) 172–182.

DOI: 10.1106/3066-1l81-j80g-w6qx

[9] J. Liu, Y. He, H. Chang, Y. Guo, H. Li, B. Pan, Simultaneously improving flame retardancy, water and acid resistance of ethylene vinyl acetate copolymer by introducing magnesium hydroxide/red phosphorus co-microcapsule and carbon nanotube, Polym. Degrad. Stab. 171 (2020), 109051.

DOI: 10.1016/j.polymdegradstab.2019.109051

[10] W. Qin, A. Kolooshani, A. Kolahdooz, S. S. Samandari, S. Khazaei, A. Khandan, F. Ren, D. Toghraie, Coating the magnesium implants with reinforced nanocoposite nanoparticles for use in orthopedic applications, COLLOID SURFACE A, 621 (2021), 126581.

DOI: 10.1016/j.colsurfa.2021.126581

[11] W. Z. Hu, B. B. Wang, X. Wang, H. Ge, L. Song, J. Wang, Y. Hu, Effect of ethyl cellulose microencapsulated ammonium polyphosphate on flame retardancy, mechanical and thermal properties of flame retardant poly(butylene succinate) composite, J. Therm. Anal. Calorim. (117) 2014, 27-38.

DOI: 10.1007/s10973-014-3680-z

[12] S. Saleemi, T. Naveed, T. Riaz, H. Memon, J. A. Awan, M. I. Siyal, F. J. Xu, J. H. Bae, Surface functionalization of cotton and PC fabrics using SiO2 and ZnO Nanoparticles for durable flame retardant properties, Coatings, 10 (2020), 124.

DOI: 10.3390/coatings10020124
