Hybrid Carbon Fiber Reinforced Laminates with Interlaminar Nanofibers

Abstract:

Polyamide (PA) nanofibers (NFs) interleaves have been inserted as a continuous non-woven mat between prepreg plies of a carbon fiber reinforced (CFR) laminate during lamination. Hybridization has been made by mixing two different material scales, being the micro-scale and the nanoscale of the CFs and the NFs respectively and two different polymer types being thermosetting the matrix and thermoplastic the NFs. Final composite laminates have been produced by vacuum bagging and autoclave molding according to the consolidated industrial procedure of aeronautic parts. Traditional square CFR laminates with 20 plies have been also manufactured using the same unidirectional (UD) CFR prepreg tape with 0/90 stacking sequence for comparison. Rectangular specimens were finally extracted from the manufactured plates. Dynamic mechanical analysis (DMA) and three-point bending tests were carried out. The reduction of the glass transition temperature T_g revealed the achieved interaction among PANFs and the resin matrix. Moreover, bending strength increased up to 9% for hybrid laminates revealing that nanostructures can add functionalities to traditional composite laminates without affecting their mechanical performances.

• Periodical: Materials Science Forum (Volume 1107)
• Pages: 3-8
• DOI: https://doi.org/10.4028/p-RUz3Px
• Online since: December 2023
• Authors: Leandro Iorio*, Fabrizio Quadrini, Denise Bellisario, Alice Proietti, Nicola Gallo, Loredana Santo
• Keywords: Autoclave Molding, Carbon Fiber Reinforced Laminates, Hybrid Composite, Polyamide Nanofibers

References

[1] S.G. Leão, M.G. Martins, N.C.F. Menezes, F.L.R.M. Limam, C.F. Silva, G.C. Arantes, A.F. Ávila, Experimental multi-scale analysis of carbon/epoxy composites nano-reinforced by carbon nanotubes/multi-layer graphene, Mater. Res. 20 (2017) 134-142.

DOI: 10.1590/1980-5373-mr-2017-0976

[2] G. Tefera, G. Bright, S. Adali, Flexural and shear properties of CFRP laminates reinforced with functionalized multiwalled CNTs, Nanocomposites 7(1) (2021) 141-153.

DOI: 10.1080/20550324.2021.1961507

[3] L. Iorio, L. Santo, F. Quadrini, D. Bellisario, D. Benedetti, J. Agnelli, Carbon fiber laminates with interlaminar carbon nanotubes, Mater. Plast. 57(1) (2020) 80-85.

DOI: 10.37358/mp.20.1.5314

[4] F. Quadrini, D. Bellisario, L. Iorio, A. Proietti, N. Gallo, L. Santo, Autoclave molding of carbon fiber laminates with interlaminar carbon nanotubes, Proceedings of ASME 2022 17th International Manufacturing Science and Engineering Conference, MSEC 2022 volume 2 (2022).

DOI: 10.1115/msec2022-85480

[5] M. Arai, Y. Noro, K. Sugimoto, M. Endo, Mode I and mode II interlaminar fracture toughness of CFRP laminates toughened by carbon nanofiber interlayer, Compos Sci Technol. 68 (2008) 516 – 525.

DOI: 10.1016/j.compscitech.2007.06.007

[6] S. Mrzljak, B. Zanghellini, L. Gerdes, R. Helwing, R. Schuller, G. Sinn, H. Lichtenegger, F. Walther, H. Rennhofer, Effect of carbon nanofibre orientation on fatigue properties of carbon fibre-reinforced polymers, J Compos Mater, 0 (2023) 1-16.

DOI: 10.1177/00219983221150496

[7] K. Kanari, M. R. Wisnom, R. Harniman, S. J. Eichhorn, Interlaminar fracture toughness of carbon fibre composites with electrospun nanofibrous interleaves of polystyrene and cellulose nanocrystals, J Mater Sci 57 (2022) 21080–21103.

DOI: 10.1007/s10853-022-07953-8

[8] J. Nasser, L. Zhang, H. Sodano, Aramid nanofiber interlayer for improved interlaminar properties of carbon fiber/epoxy composites, Composites Part B 197 (2020).

DOI: 10.1016/j.compositesb.2020.108130

[9] L. Daelemans, S. Van der Heijden, I. De Baere, H. Rahier, W. Van Paepegem, K. De Clerck, Nanofibre bridging as a toughening mechanism in carbon/epoxy composite laminates interleaved with electrospun polyamide nanofibrous veils, Compos Sci Technol 117 (2015) 244 – 256.

DOI: 10.1016/j.compscitech.2015.06.021

[10] R. Mohammadi, M. A. Najafabadi, H. Saghafi, M. Saeedifar, D. Zarouchas, A quantitative assessment of the damage mechanisms of CFRP laminates interleaved by PA66 electrospun nanofibers using acoustic emission, Compos Struct 258 (2021).

DOI: 10.1016/j.compstruct.2020.113395

[11] C. Monteserín, M. Blanco, N. Murillo, A. Pérez-Márquez, J Maudes, J. Gayoso, J. M. Laza, E. Aranzabe, J. L. Vilas, Effect of Different Types of Electrospun Polyamide 6 Nanofibres on the Mechanical Properties of Carbon Fibre/Epoxy Composites, Polymers 10 (2018).

DOI: 10.3390/polym10111190
