Quasi-Isothermal Forging of Steel-Encapsulated Ti-6Al-4V Billets

Abstract:

Isothermal forging is a common method for manufacturing titanium alloys, but it involves complex processes and equipment. The oxidation of titanium leads to the formation of an alpha-case, which in turn promotes increased crack formation. To prevent this, inert gas is typically required. However, by encapsulating the titanium billet (Ti-6Al-4V) in a steel casing made of AISI 316L, a quasi-isothermal process can be achieved without the need for inert gas. This method maintains protection against oxidation while simultaneously reducing cooling. The sealing of the capsules is crucial to ensure that the titanium is effectively enclosed and protected from the surrounding gases. In this study, various encapsulation methods are compared, including rotary friction welding, diffusion bonding, and press-fitting a lid with an interference fit. The investigation involves differing contact conditions between the titanium and steel sleeve, as well as steel wall thicknesses of 2 mm and 4 mm. These factors showed no impact on the material flow or microstructure of the formed components. Encapsulation can prevent the formation of an alpha-case. Intermetallics form between the titanium and the steel capsule, depending on the contact conditions. The use of graphite as a separating agent prevents the formation of them.

• Periodical: Materials Science Forum (Volume 1186)
• Pages: 13-24
• DOI: https://doi.org/10.4028/p-c0Lqa2
• Online since: April 2026
• Authors: Jytte Möckelmann*, Julius Peddinghaus, Kai Brunotte, Bernd Arno Behrens
• Keywords: Die Forging, Quasi-Isotherm, Steel, Titanium

References

[1] M. Najafizadeh, S. Yazdi, M. Bozorg, M. Ghasempour-Mouziraji, M. Hosseinzadeh, M. Zarrabian, P. Cavaliere, Classification and applications of titanium and its alloys: A review, Journal of Alloys and Compounds Communications. 3 (2024) 100019.

DOI: 10.1016/j.jacomc.2024.100019

[2] C. Leyens, M. Peters, Titanium and Titanium Alloys. Fundamentals and applications. Wiley, Weinheim, 2003.

[3] S. R. Shial, M. Masanta, D. Chaira, Recycling of waste Ti machining chips by planetary milling: Generation of Ti powder and development of in situ TiC reinforced Ti-TiC composite powder mixture, Powder Technol. 329 (2018) 232–240.

DOI: 10.1016/j.powtec.2018.01.080

[4] A. Zaki, S. El-Hadad, W. Khalifa, Thermal Oxidation Effects on Sub-Surface Microstructure and‎ Mechanical‎ Properties of Cast and Forged α/β Titanium Alloys‎, International Journal of Materials Technology and Innovation. 5(1) (2025) 50-58.

DOI: 10.21608/ijmti.2025.436308

[5] V. Deshmukh, R. Kadam, S. S. Joshi, Removal of alpha case on titanium alloy surfaces using chemical milling, Machining Science and Technology. 21(2) (2017) 257–278.

DOI: 10.1080/10910344.2017.1284558

[6] S. L. Semiatin, V. Seetharaman, I. Weiss, The thermomechanical processing of alpha/beta titanium alloys, JOM. 49 (1997) 33-39.

DOI: 10.1007/BF02914711

[7] F. Klocke, Fertigungsverfahren 4. Berlin, Heidelberg: Springer Berlin Heidelberg 2017.

DOI: 10.1007/978-3-662-54714-4

[8] J. Zhang, A. Kutzsche, K. Rosenberg, C. Leyens, B. Viehweger, A Novel Canning Technology for Forging of Gamma-TiAl Alloys, Materials Science Forum. 546-549 (2007) 1421–1426.

DOI: 10.4028/www.scientific.net/MSF.546-549.1421

[9] S. Germain Careau, E. Ulate-Kolitsky, B. Tougas, Direct powder forging—a new approach for near net shape processing of titanium powders, Powders. 2(1) (2023) 21-31.

DOI: 10.3390/powders2010002

[10] J. Möckelmann, J. Siring, J. Peddinhaus, H. Wester, K. Brunotte, B.-A. Behrens, Isothermes und sauerstofffreies Umformen von Titan, wt Werkstattstechnik online. 114(10) (2024) 578-587.

DOI: 10.37544/1436-4980-2024-10-6

[11] J. Siring, D. Brahimi, J. Möckelmann, H. Wester, J. Uhe, B.-A. Behrens, Numerical process design for hot forging of steel encased titanium workpieces, Materials Research Proceedings, 54 (2025) 859-867.

DOI: 10.21741/9781644903599-92

[12] J. Möckelmann, J. Siring, J. Bosse, J. Peddinghaus, H. Wester, K. Brunotte, B.-A. Behrens, Numerical Simulation and Experimental Validation of Quasi-Isothermal Die Forging for Steel-Encased Ti-6Al-4V Billets. (2026) WGP Congress (in press).

[13] Z. L. An, F. Z. Xuan, S. T. Tu, Microstructure and Mechanical Performance of Diffusion Bonding Joints of 316l Ss with Ni Interlayer, Advanced Materials Research. 631-632 (2013) 254-259.

DOI: 10.4028/www.scientific.net/AMR.631-632.254

[14] DIN 6507-1, Metallische Werkstoffe – Härteprüfung nach Vickers – Teil 1: Prüfverfahren, Ausgabe 2024-01-00.

[15] H. Ma, G. Qin, P. Geng, F. Li, B. Fu, X. Meng, Microstructure characterization and properties of carbon steel to stainless steel dissimilar metal joint made by friction welding, Materials & Design. 86 (2015) 587-597.

DOI: 10.1016/j.matdes.2015.07.068

[16] S. Germain Careau, B. Tougas, E. Ulate-Kolitsky, Effect of Direct Powder Forging Process on the Mechanical Properties and Microstructural of Ti-6Al-4V ELI. Materials. 14(16) (2021) 4499.

DOI: 10.3390/ma14164499

[17] D. F. Mo, T. F. Song, Y. J. Fang, X. S. Jiang, C. Q. Luo, M. D. Simpson, Z. P. Luo, A review on diffusion bonding between titanium alloys and stainless steels. Advances in Materials Science and Engineering, 2018(1) (2018) 8701890.

DOI: 10.1155/2018/8701890
