The Study on the Dynamic Characteristic of High Speed Machine Tool and Experiment Validate

Abstract:

One of the important factors resulting in the high-speed machinery performance is its machine tool dynamic characteristic. It will directly influence the final manufacturing capability of the machinery and it is also the important criterion of evaluating machinery performances. Especially, the dynamic characteristic of spindle assembly has large effect on manufacturing capability of machinery. So it is very important both analyzing dynamic-static characteristic of the spindle assembly and machine tool of high-speed machinery and studying the effect to machinery function. Using Finite Element Analysis software did a Finite Element Analysis of spindle assembly of the high-speed machine tool, and some experiments are done to validate the result the Finite Element Analysis results.

• Periodical: Materials Science Forum (Volumes 471-472)
• Pages: 765-769
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.471-472.765
• Online since: December 2004
• Authors: Yi Min Zhang, Xiu Li Lin, Xiao Dong Wang, Guang Qi Cai
• Keywords: Finite Element Analysis (FEA), High-Speed Machine Tool, Modal Analysis, Structure Design

References

[1] X.S. Mei, M. Tsutsumi, T. Yamazaki, et al: Machine Tool & Manufacturing Vol. 41 (2001), p.1405.

[2] M. Elhachimi, S. Torbaty and P. Jiyot: Machine Tool & Manufacturing Vol. 39 (1999), p.569.

[3] W.L. Chi, J.F. Tu and J. Kamman: Machine Tool & Manufacturing, Vol. 43 (2003), p.1035.

[4] S. Vafaei, H. Rahnejat and R. Aini: Machine Tool & Manufacturing Vol. 42 (2002), p.1223.

[5] S.M. Kim, S.K. Lee and K.J. Lee, Advanced Manufacturing Technology Vol. 19 (2002), p.551.

[6] S.M. Kim, K.J. Lee and S.K. Lee: Machine Tool & Manufacturing Vol. 42 (2002), p.365.

[7] J.S. Chen and I.C. Dwang: Machine Tool & Manufacturing Vol. 40 (2000), p.513.

[8] A. Jeang, T.K. Chen and C.L. Hwan: Advanced Manufacturing Technology Vol. 20 (2002), p.907.
