The Effect of the Graphitizing Heat Treatment and Boron Content on Boron Distribution in High Carbon Steel

Abstract:

It is convenient to analyze the distribution of boron in high carbon steel with boron, simply using neutron-induced radiography with a neutron fluency of 1.9 x 1013 [cm-2]. It was revealed by the neutron-induced radiography that the distribution of boron was dependent on boron contents, graphitizing temperature and time. The density of boron track increased with increasing boron contents. But the density of the boron track and graphite in high carbon steel graphitized at 700°C is higher than that of high carbon steel graphitized at 750°C. The density of graphite in high carbon steel also depends upon the content of boron and the graphitizing temperature. The shape of the boron track was changed from sphere to rod type when annealed at 800°C, in steel containing 50ppm of boron, due to different phases of boride. The distribution of boron segregation or boronrich precipitates in high carbon steel was well documented with a neutron-induced radiography, but the direct relationship between graphite and boron was not clarified by it. Furthermore, the analysis of electron probe X-ray microanalyzer (EPMA) also showed that the high amount of boron coexisted with carbon in graphite in high carbon steel.

• Periodical: Materials Science Forum (Volumes 475-479)
• Pages: 4157-4160
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.475-479.4157
• Online since: January 2005
• Authors: Kee Do Woo, S.W. Kim, Dong Ki Kim
• Keywords: Boron Distribution, Graphitizing Heat Treatment, Neutron Induced Radiography

References

[1] Encyclopedia of Materials Science and Engineering, ed., by M.B. Bever, Vol. 1, (Pergamon Press, Oxford, England 1986, pp.405-407).

[2] K.D. Woo, Y.K. Park, S.W. Kim, Y.C. Jin: A study on the effect of alloying elements on graphitization in high carbon steel, Final Report to POSCO (95K012), Chonbuk National University, Korea (1996).

[3] K.D. Woo and Y.K. Park: Graphitization behavior of Fe-Si-Mn-B system and Fe-Ni-B system high carbon steel, Final Report to POSCO (96KC043), Chonbuk National University, Korea (1997).

[4] A. Brown, J.D. Garnish and R.W.K. Honeycomb: Mater. Sci. Vol. 8 (1974), p.317.

[5] D.T. Llewellyn: Ironmaking and steelmaking, Vol. 20 (1993), p.338.

[6] J.S. Jang: Final report of Korea Atomic Energy Research Institute (KAERI)/ PR-2095 (2000), p.23.

[7] W. C. Jeong: Met. Mater. -Int. Vol. 9 (2003), p.179.

[8] K.D. Woo: Effect of boron for nucleation of graphite formation in high carbon steel with neutron radiography, Report to Ministry of Science & Technology, Chonbuk National University, Korea (2001).

[9] T. Iwamoto: CAMP-ISIJ Vol. 8 (1995), p.1378.

[10] R.W. Fountain and J. Chipman: Trans. AIME Vol. 224 (1962), p.599.

[11] Y. Kawabata: CAMP-ISIJ Vol. 3 (1990), p.754. Fig. 6 EPMA of graphite in B2 steel annealed at 700℃ for 25hrs. (a) Secondary electron image (b) C image (c) B image.
