Characterisation of Titanium Nitride Thin Films Deposited by Cathodic Arc Plasma Technique on AISI D6 Tool Steel

Abstract:

TiN thin film has been produced on the surface of AISI D6 tool steel by using a titanium interlayer. In this work, the morphology, the microstructure and interface depth profile of TiN films deposited at two substrate temperatures (220 oC and 450 oC) in the coating process are presented and discussed. The AISI D6 tool steel substrates were coated with titanium thin film as the underlayer and with TiN thin film as the top layer. They were deposited by conventional cathodic arc process. The surfaces of TiN films were observed by scanning electron microscopy (SEM). The microstructure of these samples was analysed by X-ray diffractometry (XRD). The influence of the substrate temperature on the TiN film-Ti film-AISI D6 interface region were investigated by energy dispersive spectrometry (EDS) and its cross section were observed using backscattered electron image (BEI). The results showed that TiN films deposited at 220 oC formed a film of strongly (111) preferred orientation, while in 450 oC formed a film of (111) and (220) preferred orientation. The thickness of the TiN films increased with increasing substrate temperature. The results show that the interface region of the TiN film-Ti film-AISI D6 substrate system was significantly improved when higher substrate temperature during deposition is used.

• Periodical: Materials Science Forum (Volumes 498-499)
• Pages: 717-721
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.498-499.717
• Online since: November 2005
• Authors: R.A. Vieira, Maria do Carmo de Andrade Nono
• Keywords: AISI D6 Tool Steel, Cathodic Arc Technique, TiN Thin Film

References

[1] A Schulz, HR Stock, P Mayr, J Staeves, D Schmoeckel, Surf. Coat. Technol. 94-95 (1997), pp.446-450.

[2] Z Iqbal, A Rauf, A Ali, A ul Haq, AQ Khan, Vacuum 51 (1998), pp.629-633.

DOI: 10.1016/s0042-207x(98)00263-2

[3] PV Kola, S Daniels, DC Cameron, MSJ Hashmi, J. of Materials Processing Technology 56 (1996), pp.422-430.

[4] MH. Staia, B Lewis, J Cawley, T Hudson, Surf. Coat. Technol. 76-77 (1995), pp.231-236.

[5] R Morita, K Azuma, S Inoue, R Miyano, H Takikawa, A Kobayashi, E Fujiwara, H Uchida, M Yatsuzuka, Surf. Coat. Technol. 136 (2001), pp.207-210.

DOI: 10.1016/s0257-8972(00)01057-4

[6] RA Vieira, MCA Nono, NC Cruz, Phys. Stat. Sol. (b) 232 (2002), pp.116-120.

[7] YY Guu, JF Lin, Wear 194 (1996), pp.22-29.

[8] P Patsalas, C Charitidis, S Logothetidis, Surf. Coat. Technol. 125 (2000), pp.335-340.
