Modified Fabric and Its Electromagnetic Protection Characteristics

Abstract:

A metallic modification technique on fabric is put forward in this paper. Morphologies and element analysis of modified fabric samples with copper and nickel-iron double films were carried out by using SEM and EDX. Shielding effectiveness (SE) on the samples was tested within 0.1~1000MHz and 1.5~18GHz. Within 0.1~1000MHz, modified fabric SE is between –93dB and –110dB. Two nickel-plated methods were compared. The measurement results of two modified fabric indicate that nickel-iron alloy films are better than nickel film on SE. With the advantages of low cost, flexibility , high electromagnetic protection characteristics, the modified fabric has a widely applicable foreground.

• Periodical: Materials Science Forum (Volumes 510-511)
• Pages: 306-309
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.510-511.306
• Online since: March 2006
• Authors: Xiao Ning Zhang
• Keywords: Electromagnetic Protection, Fabric, Shielding Effectiveness

References

[1] S.S. Tzeng and F.Y. Chang: Materials Science and Engineering A, Vol. 302, 2001, p.258.

[2] C.Y. Lee, D.E. Lee, J. Joo et al.: Synthetic Metals, Vol. 119, 2001, p.429.

[3] E.G. Han, E.A. Kim and K.W. Oh: Synthetic Metals Vol. 123, 2001, p.469.

[4] C.Y. Huang and J.F. Pai: Eur. Polym. J., Vol. 34, No. 2, 1998, p.261.

[5] T.J. Ma, C.S. Shi, J.J. Li et al.: Materials Technology of Navigation, No. 2, 1999, p.53.

[6] X.N. Zhang, Q. Wang, Q.J. Mao et al.: the New Progress on Material Science and Engineering '2000, (the Metallurgy Industry Press, China 2001).
