Research on the Influence of Shields to Thermal Equilibrium of CNC Machine Tool

Abstract:

In order to investigate that shields have the effect on the thermal equilibrium of CNC machine tool, this paper applies the theory of heat transfer and finite element analysis to analyze the thermal characteristics of CNC lathe CK40A/1000. By ANSYS software, the temperature distributions of spindle engine, headstock and bearing at thermal equilibrium with/without shields are obtained. By analyzing thermal equilibrium patterns and experiments, the temperature of spindle bearings with shields are 3-4 higher than without shields at thermal equilibrium. And shields have less influence on the temperature gradient of tool inner thermal sources.
