Thermal Activation of CFRP with Embedded NiTi Shape Memory Wires

Abstract:

The possibility of uniting two or more different materials to obtain structures capable to feel and adapt to environmental alterations and operational conditions, has been leading to the development of active composites with functional properties that makes possible the control of shape, vibration, rigidity and/or structural integrity monitoring. These characteristics are very well accepted in modern technological applications. In this context, active composites were manufactured using pre-impregnated (Pre-Pregs) of carbon fiber reinforced polymer (CFRP) and NiTi shape memory alloy (SMA) thin wires in different conditions. The functional capacity of the obtained CFRP-NiTi smart composites was verified through detection of buckling and thermal contraction/expansion effects by electrical heating of the NiTi wires inside the CFRP matrix. Although the NiTi wires represent a minimum volumetric fraction in the CFRP-NiTi produced systems, its influence was evidenced.

• Periodical: Materials Science Forum (Volume 643)
• Pages: 19-28
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.643.19
• Online since: March 2010
• Authors: Zoroastro Tôrres Vilar, Carlos José de Araújo, Rômulo Pierre Batista Dos Reis
• Keywords: Active Composite, Electrical Resistance, NiTi Alloy, Smart Materials, Smart Structure, Thermal Buckling

References

[1] A. Tebaldi, L. dos S. Coelho and V. L. Junior: Detecção De Falhas Em Estruturas Inteligentes Usando Otimização por Nuvem de Partículas: Fundamentos e Estudo de Casos. (Controle & Automação, Brazil, 2006).

DOI: 10.1590/s0103-17592006000300006

[2] V. Michaud: Can Shape Memory Alloy Composites be Smart?, (Scripta Materialia, Switzerland, 2003).

[3] J. Loughlan, S.P. Thompson and H. Smith: Buckling Control Using Embedded Shape Memory Actuators and the Utilization of Smart Technology in Future, (Carbon, UK, 2002).

DOI: 10.1016/s0263-8223(02)00193-9

[4] B. Jang and T. Kishi: Thermomechanical Response of TiNi Fiber-Impregnated CFRP Composites, (Materials Letters, Japan, 2005).

DOI: 10.1016/j.matlet.2005.03.027

[5] K. Otsuka and C.M. Wayman in: Shape Memory Materials. Cambridge University Press, Cambridge, UK, (1998), in press.

[6] Y. Xu, K. Otsuka, H. Nagai, H. Yoshida, R. Oishi, H. Horikawa and T. Kishi: A New Method for Fabricating SMA/CFRP Smart Hybrid Composites. (Intermetallics, Japan, 2002).

DOI: 10.1016/s0966-9795(02)00011-0

[7] B.K. Jang and T. Kishi: Adhesive strength between TiNi fibers embedded in CFRP composites, (Materials Letters, Japan, 2005).

DOI: 10.1016/j.matlet.2005.01.006

[8] D. D. L. Chung: Structural health monitoring by electrical resistance measurement. Smart Materials and Structures, UK, 2001).

[9] C. J. De Araújo, L. F. A. Rodrigues, J. F. Coutinho Neto, R. P. B. Reis and In: Fabrication and static characterization of carbon-fiber-reinforced polymers with embedded NiTi shape memory wire actuators, (Smart Materials and Structures, Brazil, 2008). CFRP-NiTi Buckling (µm) Temperature (ºC) As received wires 17. 45 (± 0. 56) 63 Annealed wires 1. 66 (± 0. 34) 75 Trained wires 2. 36 (± 0. 35) 70.

DOI: 10.1088/0964-1726/17/6/065004
