Heat Balance of the Model Ingot Head
p.533

HomeMaterials Science ForumMaterials Science Forum Vol. 649Heat Balance of the Model Ingot Head

Heat Balance of the Model Ingot Head

Abstract:

The paper brings data about heat balance of the killed steel ingot head. The balance is obtained on basis of the temperature measurement in the system: ingot body - ingot head - ingot mould - insulating sleeves – radiation shield - ambient. The measurements were performed using model sys-tem (1:5) of the 20000 kg flat ingot. The balance shows that about 86% of the heat issued during solidification of the ingot head is transferred to the ingot mould through the insulating sleeves. In order to decrease this heat, insulating sleeves of low thermal conductivity are required, which should allow reducing dimensions of the ingot head and increasing the metal yield.

You might also be interested in these eBooks

View Preview

Info:

Periodical:

Materials Science Forum (Volume 649)

Pages:

533-538

DOI:

https://doi.org/10.4028/www.scientific.net/MSF.649.533

Citation:

Cite this paper

Online since:

May 2010

Authors:

Witold K. Krajewski

Keywords:

Heat Balance, Heat Exchange, Ingot-Head, Solidification, Steel Ingot

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] W.K. Krajewski and J.S. Suchy: Mater. Sci. Forum, this issue.

Google Scholar

[2] W.K. Krajewski, J.S. Suchy, A.L. Greer and P. Schumacher: Development of Environmentally Friendly Cast Alloys and Composites, Marie Curie TOK-DEV Project No. MTKD-CT-2006042468, AGH University of Science and Technology - University of Cambridge - Montanuniversität Leoben (in progress).

Google Scholar

[3] W.K. Krajewski: Model Investigations of Solidification of the Killed Steel Flat Ingot. Submitted to Archiv. Metal. Mater. in (2008).

Google Scholar
