The Influence of Eutectic Morphology on the Impact Properties of High Pressure Die Cast Mg-Rare-Earth Alloys

Abstract:

The impact properties of high-pressure die cast Mg-RE alloys were investigated. It was found that, for rare earth contents between 2-4 wt.%, the Mg-La and Mg-Nd alloys performed better than the Mg-Ce alloys in un-notched tests. The notched results appear to be related to the amount of intermetallic. In contrast, the un-notched results indicate that at some compositions the Mg-La alloys out-performed the other alloys when compared to the amount of intermetallic. It was apparent that a lamellar eutectic structure can improve the un-notched impact properties of Mg-RE based alloys even when this is not evidenced in tensile test or notched impact results.

You might also be interested in these eBooks

View Preview

Info:

Periodical:

Materials Science Forum (Volumes 654-656)

Pages:

683-686

DOI:

https://doi.org/10.4028/www.scientific.net/MSF.654-656.683

Citation:

Cite this paper

Online since:

June 2010

Authors:

Mark Easton, Katharina Strobel, Su Ming Zhu, Mark A. Gibson, Jian Feng Nie

Keywords:

High Pressure Die Casting (HPDC), Impact Property, Magnesium Alloy, Rare Earth (RE)

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] A. Luo: Int. Mater. Rev., Vol. 49, (2004), p.13.

Google Scholar

[2] M.A. Gibson, M.A. Easton, V. Tyagi, M.T. Murray, and G.L. Dunlop: Magnesium Technology 2008. (The Metals, Minerals and Materials Society, 2008), p.227.

Google Scholar

[3] N. Birbilis, M.A. Easton, A.D. Sudholz, S.M. Zhu, and M.A. Gibson: Corr. Sci., Vol. 51, (2009), p.683.

Google Scholar

[4] T.L. Chia, M.A. Easton, S.M. Zhu, M.A. Gibson, N. Birbilis, and J.F. Nie: Intermetallics, Vol. 17, (2009), p.481.

Google Scholar

[5] M.A. Easton, S.M. Zhu, N. Birbilis, A.D. Sudholz, M.A. Gibson, and J.F. Nie, in 8th International Conference Magnesium Alloys and Their Applications, K.U. Kainer, Editor. 2009, Wiley-VCH Verlag GmbH & Co. KGaA, Weinheim, Germany, p.75.

Google Scholar

[6] M.A. Gibson, S. Zhu, M.A. Easton, and J.F. Nie, in Mangesium Technology 2010, S.R. Agnew, et al., Editors. 2010, (TMS, Warrendale, PA), p.233.

Google Scholar

[7] S.M. Zhu, M.A. Gibson, M.A. Easton, and J.F. Nie: Scripta Mater., (2010), doi: 10. 1016/j. scriptamat. 2010. 02. 005.

Google Scholar

[8] L.L. Rokhlin, Magnesium alloys containing rare earth metals. (Taylor & Francis, 2003).

Google Scholar

[9] W. Kurz and D. Fisher, Fundamentals of solidification, 4th edition. (Trans Tech Publications, Switzerland., 1998).

Google Scholar
