Calculated Transmittance Spectra of One-Dimensional Photonic Crystals

Abstract:

The time-harmonic electromagnetic wave through the one-dimensional photonic crystals (1-D PCs) perpendicularly has been considered. By theoretical calculation with characteristic matrix method, the dispersion curves and the transmittance spectra were calculated. From the dispersion curves, it shown that the lowest band gap is at frequencies between 0.23~0.32, i.e. it is around 0.27. In addition, according to the transmittance spectra, it shown that the transmittance declined from 40.6% to 0 dramatically along with the periodicity N of the periodically stratified medium increased from 2 to 1024, it also exhibited that when the periodicity N was upped to 8, it could form 1-D PCs.

• Periodical: Materials Science Forum (Volumes 663-665)
• Pages: 709-712
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.663-665.709
• Online since: November 2010
• Authors: Yuan Ming Huang, Qing Lan Ma, Yun Gao Cai
• Keywords: Characteristic Matrix, Dispersion Curve, One-Dimensional Photonic Crystal, Transmittance Spectrum

References

[1] Y.M. E. Yablonovitch: Phys. Rev. Lett. Vol. 58 (1987), p. (2059).

[2] S. John: Phys. Rev. Lett. Vol. 58 (1987), p.2486.

[3] Y. M. Huang et al.: Chin. J. Lasers Vol. 35 (2008), p.280.

[4] Y. M. Huang et al.: Acta Optica Sinica Vol. 29 (2009), p.1160.

[5] M. Born and E. Wolf: Principles of Optics, 6th ed (Pergamon Press, Oxford 1980).
