Evaluation of the Iron Loss of the Actual Stator Core to Achieve High Efficiency of the Rotating Machine

Abstract:

In this paper, the iron loss of an actual stator core of the complex configuration was evaluated by using the proposed effective magnetic path length and the excitation inner core, which were developed in this research. The iron loss of an actual stator core in the manufacturing process was described. Iron losses of actual stator cores before and after the varnish processing were measured using the excitation inner core of several kinds of shapes. As a result, iron losses of actual stator cores evaluated using the proposed effective magnetic path length were within appropriate values.

• Periodical: Materials Science Forum (Volume 670)
• Pages: 447-454
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.670.447
• Online since: December 2010
• Authors: Mohachiro Oka, Tugunori Kanada, Takayuki Kai, Masato Enokizono
• Keywords: Iron Loss, Rotating Machine, Stator Core

References

[1] K. Yamamoto, E. Shimomura, K. Yamada, T. Sasaki： Effects of External Stress on Magnetic Properties in Motor Cores, Transactions of The Institute of Electrical Engineers of Japan, Vol. 17-A, No. 3, (1997).

[2] C. Kaido, H. Moge, K. Hanzawa, The Effect of Short Circuit between Laminated Steel Sheets on the Performance of Lamination Core of Motor, Transactions of The Institute of Electrical Engineers of Japan, Vol. 123-A, No. 9, pp.857-862, (2003).

DOI: 10.1541/ieejfms.123.857

[3] M. Oka, O. Nakazaki, T. Kanda and M. Enokizono, Measurement of Material Properties of Actual Electrical Steel Stator Core to Achieve High Efficiency of Rotating Machines, Bulletin of Topical Symposium of the Magnetic Society of Japan, pp.27-32(2008).

[4] N. Iwasaki, T. Todaka, M. Enokizono and Y. Ishihara, Development of Simplified Evaluation Method of Iron Losses in Actual Stator Cores of Rotating Machines, 9th International Workshop on 1 & 2 Dimensional Magnetic Measurement and Testing.

[5] T. Kai, M. Oka, T. Kanada and M. Enokizono, Iron Loss Evaluation of Stator Cores for Rotating Machines, Proceedings of the 11th Japan Korea Joint Symposium on the Applied Electromagnetics, pp.35-36, (2009).

[6] M. Oka, T. Kanada, T. Kai*, M. Enokizono, Iron Loss Evaluation for Improvement of a Building Factor of a Rotating Machine, Proceedings of The 21th Symposium on Electromagnetics and Dynamics, pp.311-316, (2009).
