Investigation on Post Treatment of Nano-Size Silver Conductive Film

Abstract:

To achieve a satisfied conductivity of nano-size silver printed circuit, post deal with nano-size silver conductive film was investigated. Based on the preparation of nano-size conductive ink and conductive circuit, the coated conductive film was treated by series concentrations of hydrochloride solutions, and then scanned by laser beam. The influence of resolutions concentration and dipping time were investigated separately. Atomic force microscopy (AFM), fourier transform infrared (FTIR) and four-probe tester, were applied to characterize the different tested samples. It was found that when the coated silver conductive ink samples were dipped in 20% hydrochloride for 60min, 15°C before laser scanning, the conductivity reaches 0.3Ω/□. It is therefore considered that the “dip in” method provide an efficient alternative to improve the conductivity which from nano-size silver ink.

• Periodical: Materials Science Forum (Volumes 675-677)
• Pages: 1117-1120
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.675-677.1117
• Online since: February 2011
• Authors: Wen Zhao, Lu Hai Li, Zhi Qing Xin, Luo Bu Danzeng
• Keywords: Conductive Ink Coating, Conductivity, Dip in Laser

References

[1] Jung-Tang Wu, Steve Lien-Chung Hsu and Ming-Hsiu Tsai, in: Conductive silver patterns via ethylene glycol vapor reduction of ink-jet printed silver nitrate tracks on a polyimide substrate, Thin Solid Films. 517 (2009) 5913–5917.

DOI: 10.1016/j.tsf.2009.04.049

[2] Kan-sen Chou ect, in: Fabrication and sintering effect on the morphologies and conductivity of nano-Ag particle films by the spin coationg method, Nanotechnology. 16(2005) 779-784.

DOI: 10.1088/0957-4484/16/6/027

[3] JI Li-Na, TANG Xiao-Feng and YANG Zhen-Guo, in: Research and development trends of nano silver conductive ink for ink-jer printing of PCB. Ink-Jet Printing Technology. 6(2009), 26-30.

DOI: 10.1016/b978-0-85709-230-4.00002-9

[4] Fang Yi, in: The Status and Development of Inkjet Conductive Ink. Ink-Jet Space. 8(2009), 59-60.

[5] Daisuke Wakuda, Mariko Hatamura and Katsuaki Suganuma, in: Novel method for room temperature sintering of Ag nanoparticle paste in air, Chemical Physics Letters. 441(2007) 305-308.

DOI: 10.1016/j.cplett.2007.05.033

[6] Zongtao Zhang, Bin Zhao, and Liming Hu, in: PVP protective mechanism of ultrafine silver powder synthesized by chemical reduction processes, Journal of Solid State Chemistry. 121(1996), 105-110.

DOI: 10.1006/jssc.1996.0015

[7] Hongshui Wang, Xueliang Qiao and Jianguo Chen, in: mechanisms of PVP in the preparation of silver nanoparticles, Materials Chemistry and Physics 94(2005) 449-453.

DOI: 10.1016/j.matchemphys.2005.05.005
