Preparation and Characterization of Diamond-TiC-Ti-Ag/Cu Gradient Metallization System

Abstract:

A novel kind of diamond-TiC-Ti gradient interlayer has been successfully obtained between self-standing diamond and Ag/Cu films by combining Ti ion implanted into the achieved CVD diamond films by MEVVA with depositing Ti layer and by magnetron sputtering and annealing in vacuum. In the metallization system, RF sputtering was also utilized to deposit Ag/Cu films consistent with target composition based on orthogonal experimental design. Transition from Ti to Ag/Cu could be controlled to distribute gradually through adjusting both of their deposition powers. X-ray photoelectron spectroscopy (XPS) and X-ray diffraction (XRD) results show TiC is formed and the content of Ti increases gradually in diamond and decreases in the sputtering depth profiles of the Ti-Ag/Cu film. Raman spectroscopy indicates the effects of Ti ion implantation on the structure of diamond. Gradient design leads to order-of-magnitude improvements in adhesion between diamond and Ag/Cu films, which can be a good choice for heat sink.

• Periodical: Materials Science Forum (Volume 687)
• Pages: 722-728
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.687.722
• Online since: June 2011
• Authors: Jin Long Liu, Cheng Ming Li, Liang Xian Chen, Ying Ying Zhang, Li Fu Hei, Fan Xiu Lv
• Keywords: Gradient Interlayer, Heat Sink, Ion Implant, Metallization

References

[1] T. Schubert, B. Trindade, T. Weißgäber and B. Kieback: Materials Science and Engineering: A Vol. 475(2006), p.39.

[2] T. Schuberta, Ł. Ciupińskib, W. Zielińskib, and B. Kieback: Scripta Materialia: Vol. 58(2008), p.263.

[3] V.V. Parashchuk, A.K. Belyaeva, V.V. Baranov and E.V. Telesh: Quantum Electronics Vol. 40(2010), p.301.

[4] C.H. Pan, S.M. Du, H. Li, J.Y. Li and Y.H. Xu: Transactions of Materials and Heat Treatment: Vol. 24(2003), p.59.

[5] G.F. Yin, J.M. Luo, C.Q. Zheng and H.H. Tong: Thin Solid Films Vol. 345 (1999), p.68.

[6] V. J. Trava-Airoldia, E.J. Corata, L.V. Santosa and J.R. Moroc: Material Research Vol. 6(2003), p.305.

[7] J.G. Buijnsters, P. Shankar, J.J. Ter Meulen: Surface and Coatings Technology Vol. 201(2007), p.8955.

DOI: 10.1016/j.surfcoat.2007.04.012

[8] V. J. Trava-Airoldia, E.J. Corata, L.V. Santosa and A.V. Diniz: Diamond and Related Materials Vol. 11(2002), p.532.

[9] L. Cui, G.Q. Li, W.W. Chen and Z.X. Mu: Thin Solid Films Vol. 475(2005), p.279.

[10] L. Cui, Z.X. Mu, W.W. Chen and G.Q. Li: Functional Material Vol. 2(2005), p.301.

[11] A. C. Ferrari and J. Robertson: Physical Review B Vol. 61(2000), p.14095.

[12] Y.H. Lin, H.D. Lin, C.K. Liu and M.W. Huang: Thin Solid Films Vol. 518(2009), p.1603.

[13] X. Zhang, Z.L. Wu, X.Y. Wu, L.Z. Qin: Surface and Coatings Technology Vol. 201(2007), p.5219.

[14] Y.H. Lin, H.D. Lin, C.K. Liu and M.W. Huang: Diamond and Related Materials Vol. 19(2010), p.1034.
